SMBJ5.0(C)A - SMBJ170(C)A
Document number: DS19002 Rev. 17 - 2
1 of 5
www.diodes.com
June 2009
© Diodes Incorporated
SMBJ5.0
(
C
)
A - SMBJ170
(
C
)
A
600W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
Features
• 600W Peak Pulse Power Dissipation
• 5.0V - 170V Standoff Voltages
• Glass Passivated Die Construction
• Uni- and Bi-Directional Versions Available
• Excellent Clamping Capability
• Fast Response Time
• Lead Free Finish/RoHS Compliant (Note 1)
• Green Molding Compound (No Halogen and Antimony)
(Note 2)
Mechanical Data
• Case: SMB
• Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
• Moisture Sensitivity: Level 1 per J-STD-020D
• Terminals: Lead Free Plating (Matte Tin Finish). Solderable per
MIL-STD-202, Method 208
• Polarity Indicator: Cathode Band (Note: Bi-directional devices
have no polarity indicator.)
• Marking: Information: See Page 4
• Ordering Information: See Page 4
• Weight: 0.1 grams (approximate)
Maximum Ratings @T
A
= 25°C unless otherwise specified
Characteristic Symbol Value Unit
Peak Pulse Power Dissipation
(Non repetitive current pulse derated above T
A
=
25° C) (Note 3)
P
PK
600 W
Peak Power Derating Above 25°C
P
der
4.8
W/°C
Peak Forward Surge Current, 8.3ms Single Half Sine Wave Superimposed
on Rated Load (Notes 3, 4, & 5)
I
FSM
100 A
Steady State Power Dissipation @ T
L
= 75°C PM
(AV)
5.0 W
Instantaneous Forward Voltage @ I
PP
= 35A V
BR
<100V
(Notes 3, 4, & 5) V
BR
≥
100V
V
F
3.5
5.0
V
V
Thermal Characteristics
Characteristic Symbol Value Unit
Operating Temperature Range
T
J
-55 to +150
°C
Storage Temperature Range
T
STG
-55 to +175
°C
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at http://www.diodes.com/quality/lead_free.html.
2. No purposefully added lead. Halogen and Antimony free.
3. Valid provided that terminals are kept at ambient temperature.
4. Measured with 8.3ms single half sine-wave. Duty cycle = 4 pulses per minute maximum.
5. Unidirectional units only.
Green
Top View Bottom View
Please click here to visit our online spice models database.
