SN74LVC1G3157
SCES424I –JANUARY 2003–REVISED JUNE 2015
SN74LVC1G3157 Single-Pole Double-Throw Analog Switch
1 Features 3 Description
This single-pole double-throw (SPDT) analog switch
1
• 1.65-V to 5.5-V V
CC
Operation
is designed for 1.65-V to 5.5-V V
CC
operation.
• Useful for Both Analog and Digital Applications
The SN74LVC1G3157 device can handle both analog
• Specified Break-Before-Make Switching
and digital signals. The SN74LVC1G3157 device
• Rail-to-Rail Signal Handling
permits signals with amplitudes of up to V
CC
(peak) to
• Operating Frequency Up to 300 MHz
be transmitted in either direction.
• High Degree of Linearity
Applications include signal gating, chopping,
• High Speed, Typically 0.5 ns
modulation or demodulation (modem), and signal
multiplexing for analog-to-digital and digital-to-analog
(V
CC
= 3 V, C
L
= 50 pF)
conversion systems.
• Low ON-State Resistance, Typically ≉6 Ω
(V
CC
= 4.5 V)
Device Information
(1)
• Latch-Up Performance Exceeds 100 mA Per
PART NUMBER PACKAGE BODY SIZE (NOM)
JESD 78, Class II
SOT-23 (6) 2.90 mm × 1.60 mm
• ESD Protection Exceeds JESD 22
SC70 (6) 2.00 mm × 1.25 mm
– 2000-V Human Body Model (A114-A)
SN74LVC1G3157 SOT (6) 1.60 mm × 1.20 mm
– 200-V Machine Model (A115-A)
SON (6) 1.45 mm × 1.00 mm
– 1000-V Charged-Device Model (C101)
DSBGA (6) 1.41 mm × 0.91 mm
(1) For all available packages, see the orderable addendum at
2 Applications
the end of the data sheet.
• Wearables
• Portable Computing
• Internet of Things
• Audio Signal Processing
Simplified Schematic
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
