MCRR Series
Multilayer Ceramic Capacitors
Page <1> 05/04/12 V1.1
www.element14.com
www.farnell.com
www.newark.com
Features:
Cost effective dipped radial multilayer ceramic capacitors
High reliability and performance
Applications for C0G dielectric tuned circuits and filters where low loss
and stability are required
X7R dielectric offers high capacitance values in compact sizes with
good stability
Z5U dielectric can be used in coupling and decoupling applications
where change of capacitance with temperature is not important
Conformally Coated Radial Leaded MLC
Temperature Coefficients : C0G (NP0), X7R, Z5U
200, 100, 63 / 50 Volts
Case Material : Epoxy
Lead Material : Solderable
General Information
Lead length = 25.4 minimum, Lead Diameter = 0.508
C0G (NP0) Dielectric
Size and Capacitance Specifications
EIA Characteristic
Height (H) 3.81 7.62
Width (W) 3.81 5.08
Depth (D) 2.54 3.18
Lead Spacing (L.S.) 2.54 5.08
Lead Diameter (L.D.) 0.508 0.508
Capacitance in pF
Voltage WVDC Voltage, DC Voltage, DC
Part Number 200 100 200 100
10 MCRR25100C0GJ0200
22 MCRR25220C0GJ0200
33 MCRR25330C0GJ0200
47 MCRR25470C0GJ0200
10 MCRR50100C0GJ0200
22 MCRR50220C0GJ0200
33 MCRR50330C0GJ0200
47 MCRR50470C0GJ0200
100 MCRR50101C0GJ0200
220 MCRR50221C0GJ0200
100 MCRR25101C0GJ0100
220 MCRR25221C0GJ0100
330 MCRR25331C0GJ0100
470 MCRR25471C0GJ0100
1,000 MCRR25102C0GJ0100
1,000 MCRR50102C0GJ0100
Dimensions : Millimetres
= Industry preferred values
