ABSOLUTE MAXIMUM RATINGS
(1)
SRC4382
SBFS030C – JANUARY 2006 – REVISED SEPTEMBER 2007
This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling and installation procedures can cause damage.
ESD damage can range from subtle performance degradation to complete device failure. Precision integrated circuits may be more
susceptible to damage because very small parametric changes could cause the device not to meet its published specifications.
ORDERING INFORMATION
(1)
OPERATING
PACKAGE TEMPERATURE PACKAGE ORDERING TRANSPORT MEDIA,
PRODUCT PACKAGE DESIGNATOR RANGE MARKING NUMBER QUANTITY
SRC4382IPFBT Tape and Reel, 250
SRC4382 TQFP-48 PFB – 40C to +85C SRC4382I
SRC4382IPFBR Tape and Reel, 2000
(1) For the most current package and ordering information see the Package Option Addendum at the end of this document, or see the TI
web site at www.ti.com .
Power Supplies
VDD18 – 0.3V to +2.0V
VDD33 – 0.3V to +4.0V
VIO – 0.3V to +4.0V
VCC – 0.3V to +4.0V
Digital Input Voltage: Digital Logic
RXCKI, MUTE, CPM, CS, CCLK, CDIN, CDOUT, INT, RST, MCLK, BLS, SYNC, BCKA,
– 0.3V to (VIO + 0.3V)
BCKB, LRCKA, LRCKB, SDINA, SDINB
Line Receiver Input Voltage (per pin)
RX1+, RX1 – , RX2+, RX2 – , RX3+, RX3 – , RX4+, RX4 – (VDD33 + 0.3) V
PP
Input Current (all pins except power and ground) 10mA
Ambient Operating Temperature – 40C to +85C
Storage Temperature – 65C to +150C
(1) These limits are stress ratings only. Stresses beyond these limits may result in permanent damage. Extended exposure to absolute
maximum ratings may degrade device reliability. Normal operation or performance at or beyond these limits is not specified or ensured.
Copyright © 2006 – 2007, Texas Instruments Incorporated Submit Documentation Feedback 3
Product Folder Link(s): SRC4382
