Sensing and Control
MISUSE OF DOCUMENTATION
The information presented in this product sheet (or catalogue) is for
reference only. DO NOT USE this document as product installation
information.
Complete installation, operation and maintenance information is
provided in the instructions supplied with each product.
Failure to comply with these instructions could result in death
or serious injury.
WARNING
!
Super sealed CE
Miniature limit switch
®
Features
Fully sealed - capable of working when submerged
Compact construction
Pre-wired or connector versions
Die-cast zinc housing
Wide selection of actuators
Gang mounting capability
Variable length PUR cable
Side and bottom exit cable/connector
Simple two-screw mounting
IP66/67, IP68 sealing
Benefits
Suitable for difficult operating environments
Suitable for applications where space is at a premium
Fast and easy to install
Application flexibility
Multiple switching in small spaces
Enhanced choice for application
Suitable for aggressive environments
Description
The Super sealed CE Series Miniature limit switch has been
designed for reliability in the harshest of environments. Its
robust design, corrosion limiting features, flexible PUR cable
and super sealing allows it to operate fully submerged in a
range of fluids. Its small size allows operation in confined
spaces. A range of different actuators offers flexibility in
application.
Low energy switching
In today’s demanding age of low energy controls,
electromechanical switches are frequently used in interface
directly with PLCs and other low energy devices. To
accommodate this requirement Super sealed CE offers a gold
plated contact version of the standard basic switch. This
improves reliability of switching at low currents and voltages by
protecting the contact surfaces from contamination during
operation or storage prior to use. Standard silver contacts
have the disadvantage in that the contact may tarnish under
certain environmental conditions, e.g. in the presence of
moisture.
Low energy basic switches are rated as follows:
Operating Voltage U
e 1 to 50 Vac or Vdc
Operating Current I
e 1 to 100 mA
Electrical rating
(Pending)
Designation & Utilization
Category
Rated operational current Ie (A)
at rated operational voltage Ue
VA
rating
IEC947-5-1 / EN60947-5-1
120V 240V 380V 480V 500V 600V Make Break
AC15 A600 6 3 1.9 1.5 1.4 1.2 7200 720
AC15 A300 6 3 - - - - 7200 720
AC15 B300 3 1.5 - - - - 3800 360
AC14 D300 0.6 0.3 - - - - 432 72
125V 250V
DC13 Q300 0.55 0.27 69 69
DC13 R300 0.22 0.1 28 28
New
(Pending)
