Data brief
For further information contact your local STMicroelectronics sales office.
August 2010 Doc ID 17799 Rev 1 1/3
3
STM3210C-EVAL
STM3210C-EVAL evaluation board
Features
■ Three 5 V power supply options:
–power jack
– USB connector
– daughterboard
■ Boot from user Flash, system memory or
SRAM
■ I2S audio DAC, stereo audio jack
■ 2 GByte microSD Card™ or bigger
■ Both A and B type smartcard support
■ I2C compatible serial interface 64 Kbit
EEPROM, MEMS and I/O expander
■ RS-232 channel
■ IrDA transceiver
■ USB OTG full speed, USB microAB connection
■ IEEE-802.3-2002 compliant ethernet
connector
■ Two channels of CAN 2.0A/B compliant
connection
■ Inductor motor control connector
■ JTAG and trace debug support
■ 3.2” 240x320 TFT color LCD with touch screen
■ Joystick with 4-direction control and selector
■ Reset, wakeup, tamper and user buttons
■ 4 color LEDs
■ RTC with backup battery
■ MCU consumption measurement circuit
■ Extension connector for daughterboard or
wrapping board
Description
The STM3210C-EVAL evaluation board is a
complete development platform for
STMicroelectronic's ARM Cortex-M3 core-based
STM32F107VCT microcontroller. The range of
hardware features on the board help you to
evaluate all peripherals (USB-OTG FS, ethernet,
motor control, CAN, microSD Card
TM
, smartcard,
USART, audio DAC, MEMS, EEPROM and more)
and develop your own applications.
Extension headers make it easy to connect a
daughterboard or wrapping board for your specific
application.
Table 1. Device summary
Order code Reference
STM3210C-EVAL
STM32F107VCT evaluation
board
www.st.com
