Data brief
For further information contact your local STMicroelectronics sales office.
September 2011 Doc ID 17708 Rev 3 1/3
3
STM3210E-EVAL
STM3210E-EVAL evaluation board
Features
■ Three 5 V power supply options:
–power jack
– USB connector
– daughterboard
■ Boot from user Flash, system memory or
SRAM
■ I2S audio DAC, stereo audio jack
■ 128 Mbyte MicroSD Card™ or bigger
■ Both A and B type smartcard support
■ 64 or 128 Mbit serial Flash, 512 Kx16 SRAM,
512 Mbit or 1 Gbit NAND Flash and 128 Mbit
NOR Flash
■ I2C/SMBus compatible serial interface
temperature sensor
■ Two RS-232 channels with RTS/CTS
handshake support on one channel
■ IrDA transceiver
■ USB 2.0 full speed connection
■ CAN 2.0A/B compliant connection
■ Inductor motor control connector
■ JTAG and trace debug support
■ 240x320 TFT color LCD
■ Joystick with 4-direction control and selector
■ Reset, wakeup, tamper and user buttons
■ 4 color LEDs
■ RTC with backup battery
Description
The STM3210E-EVAL evaluation board is a
complete development platform for
STMicroelectronic's ARM Cortex-M3 core-based
STM32F103ZET6 or STM32F103ZGT6
microcontroller. The range of hardware features
on the board help you to evaluate all peripherals
(LCD, SPI Flash, USART, IrDA, USB, audio, CAN
bus, smartcard, MicroSD Card, NOR Flash,
NAND Flash, SRAM, temperature sensor, audio
DAC and motor control) and develop your own
applications.
Extension headers make it easy to connect a
daughterboard or wrapping board for your specific
application.
Table 1. Device summary
Order code Reference
STM3210E-EVAL
STM32F103ZET6 or
STM32F103ZGT6 evaluation
board
www.st.com
