STM32F042C4T6数据手册
Page:
of 57 Go
若手册格式错乱，请下载阅览PDF原文件
This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to
change without notice. For further information contact your local STMicroelectronics sales office.
January 2014 DocID025463 Rev 1 1/57
STM32F042xx
ARM-based 32-bit MCU, up to 32 KB Flash, crystal-less USB
FS 2.0, CAN, 8 timers, ADC & comm. interfaces, 2.0 - 3.6 V
Data brief - preliminary data
Features
Core: ARM
®
32-bit Cortex™-M0 CPU,
frequency up to 48 MHz
Memories
– 16 to 32 Kbytes of Flash memory
– 6 Kbytes of SRAM with HW parity checking
CRC calculation unit
Reset and power management
– Voltage range: 2.0 V to 3.6 V
– Power-on/Power down reset (POR/PDR)
– Programmable voltage detector (PVD)
– Low power modes: Sleep, Stop, Standby
–V
BAT
supply for RTC and backup registers
Clock management
– 4 to 32 MHz crystal oscillator
– 32 kHz oscillator for RTC with calibration
– Internal 8 MHz RC with x6 PLL option
– Internal 40 kHz RC oscillator
– Internal 48 MHz oscillator with automatic
trimming based on ext. synchronization
Up to 37 fast I/Os
– All mappable on external interrupt vectors
– Up to 37 I/Os with 5-V tolerant capability
and 8 with independent supply V
DDIO2
5-channel DMA controller
One 12-bit, 1.0 μs ADC (up to 10 channels)
– Conversion range: 0 to 3.6 V
– Separate analog supply from 2.4 up to 3.6
Up to 15 capacitive sensing channels for
touchkey, linear and rotary touch sensors
Calendar RTC with alarm and periodic wakeup
from Stop/Standby
8 timers
– One 16-bit advanced-control timer for
6 channel PWM output
– One 32-bit and four 16-bit timers, with up to
4 IC/OC, OCN, usable for IR control
decoding
– Independent and system watchdog timers
– SysTick timer
Communication interfaces
– One I
2
C interface supporting Fast Mode
Plus (1 Mbit/s) with 20 mA current sink,
SMBus/PMBus and wakeup
– Two USARTs supporting master
synchronous SPI and modem control; one
with ISO7816 interface, LIN, IrDA, auto
baud rate detection and wakeup feature
– Two SPIs (18 Mbit/s) with 4 to 16
programmable bit frames, and with I
2
S
interface multiplexed
– CAN interface
– USB 2.0 full-speed interface, able to run
from internal 48 MHz oscillator and with
BCD and LPM support
HDMI CEC, wakeup on header reception
Serial wire debug (SWD)
96-bit unique ID
All packages ECOPACK
®
2
Table 1. Device summary
Reference Part number
STM32F042xx
STM32F042F4, STM32F042G4,
STM32F042K4, STM32F042T4,
STM32F042C4
STM32F042F6, STM32F042G6,
STM32F042K6, STM32F042T6,
STM32F042C6
LQFP48 7x7
UFQFPN48 7x7
WLCSP36
UFQFPN32 5x5
UFQFPN28 4x4
TSSOP20
LQFP32 5x5
www.st.com
