STM32F042K6T6 产品描述及参数 - ST Microelectronics（意法半导体）
制造商:
ST Microelectronics（意法半导体）
分类:
微控制器
封装:
LQFP-32
描述:
STM32F04 系列微控制器，STMicroelectronicsRISC 核芯：ARM 32 位 Cortex-M0 CPU，频率高达 48MHz CRC 计算装置 重置和电源管理 时钟管理 多达 37 个快速输入/输出 5 通道 DMA 控制器 8 个计时器 通信接口：I2C、USART、SPI、CAN、USB 2.0 全速 ### STM32F0 系列 32 位 ARM® Cortex®-M0 微控制器，STMicroelectronicsSTM32 F0 系列 32 位闪存微控制器 (MCU) 基于 ARM Cortex™-M0 核心；为嵌入式应用特别开发的核心。 STMicroelectronics 的 STM32 ARM Cortex™ M 处理器得益于 Cortex-M0 体系结构增强功能，包括数字信号处理、实时性能、低电压和低功率。 ST ARM® STM32 F0 主流系列提供 32 位性能，且特别适用于小项目或平台决策，具有易于使用功能。
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
型号编码规则在P2
导航目录
STM32F042K6T6数据手册
Page:
of 4 Go
若手册格式错乱，请下载阅览PDF原文件
For further information contact your local STMicroelectronics sales office.
June 2016 DocID028107 Rev 3 1/4
NUCLEO-XXXXKX
STM32 Nucleo-32 board
Data brief
Features
STM32 microcontrollers in 32-pin packages
Extension with Arduino
™
nano connectivity
ARM
®
mbed
™
-enabled (see http://mbed.org)
On-board ST-LINK/V2-1
debugger/programmer with SWD connector:
– Selection-mode switch to use the kit as
a standalone ST-LINK/V2-1
– USB re-enumeration capability. Three
different interfaces supported on USB:
virtual COM port, mass storage, debug
port
Flexible board power supply:
– USB VBUS
– External source
Three LEDs:
– USB communication (LD1), power LED
(LD2), user LED (LD3)
Reset push-button
Supported by wide choice of Integrated
Development Environments (IDEs) including
IAR
™
, Keil
®
, GCC-based IDEs (AC6
SW4STM32, ...)
1. Picture not contractual
Description
The STM32 Nucleo-32 board provides an
affordable and flexible way for users to try out
new concepts and build prototypes with the
STM32 microcontroller, choosing from the various
combinations of performance, power
consumption and features.The Arduino
™
nano
connectivity makes it easy to expand the
functionality of the STM32 Nucleo open
development platform with a choice of specialized
shields.The STM32 Nucleo-32 board does not
require any separate probe as it integrates the
ST-LINK/V2-1 debugger/programmer and it
comes with the STM32 comprehensive software
HAL library, together with various packaged
software examples, as well as direct access to the
ARM
®
mbed
™
on-line resources.
Table 1. Device summary
Reference Part number
NUCLEO-XXXXKX
NUCLEO-F031K6, NUCLEO-F042K6,
NUCLEO-F303K8, NUCLEO-L011K4,
NUCLEO-L031K6, NUCLEO-L432KC.
www.st.com
