Device summary
Part number Package
Flash size
(Kbytes)
Internal
RAM size
(Kbytes)
Timer functions
ADC
12-bit
DAC
12-bit
I/Os Serial interface
16-bit
timers
32-bit
timers
Others
STM32F051 - 48 MHz CPU with DAC
STM32F051R8*
LQFP64 64 8 6 1
2 x WDG,
RTC,
24-bit down
counter,
1x 16-bit
basic timer
16 1 55
2xSPI (1x with I²S), 2xI²C,
2xUSART (IrDA, ISO 7816), CEC
STM32F051C8
LQFP48 64 8 6 1 10 1 39
STM32F051K8
UFQFPN32 64 8 6 1 10 1 27
STM32F051R6
LQFP64 32 4 6 1 16 1 55
1xSPI, 1xI²S, 1xI²C, 2xUSART
(IrDA, ISO 7816), CEC
STM32F051C6
LQFP48 32 4 6 1 10 1 39
STM32F051K6
UFQFPN32 32 4 6 1 10 1 27
STM32F051R4
LQFP64 16 4 6 1 16 1 55
1xSPI, 1xI²S, 1xI²C, 1xUSART
(IrDA, ISO 7816), CEC
STM32F051C4
LQFP48 16 4 6 1 10 1 39
STM32F051K4
UFQFPN32 16 4 6 1 10 1 27
STM32F050 - 48 MHz CPU
STM32F050C6
LQFP48 32 4 5 1
2 x WDG,
RTC,
24-bit down
counter
10 - 39
1xSPI, 1xI²S, 1xI²C, 1xUSART
(IrDA, ISO 7816)
STM32F050K6
UFQFPN32 32 4 5 1 10 - 27
STM32F050C4
LQFP48 16 4 5 1 10 - 39
1xSPI, 1xI²S, 1xI²C, 1xUSART
(IrDA, ISO 7816)
STM32F050K4
UFQFPN32 16 4 5 1 10 - 27
Supply voltage 1.8/2.0 to 3.6 V for all devices
Note: * STM32F051R8 is available now. All other devices will be available early Q2/2012
Block diagram
1x 16-bit motor control
PWM
Synchronized AC timer
Control
1x 32-bit timer
5x 16-bit PWM timers
System
27/39/55 I/Os
Calendar RTC
Power supply
1.8 V regulator
POR/PDR/PVD
Internal RC oscillators
40 kHz + 8 MHz
Clock control
PLL
2x window watchdogs
(independent and system)
Cyclic redundancy
check (CRC)
Xtal oscillators
32 kHz + 4 ~32 MHz
SysTick timer
Touch-sensing controller
APB bus
5-channel DMA
ARM Cortex-M0 CPU
48 MHz
Nested vector
interrupt
controller (NVIC)
SW debug
AHB-Lite bus matrix
1x 16-bit basic timer
Analog
1x 12-bit ADC
16 channels / 1 MSPS
1-channel 12-bit DAC
2x analog comparator
Up to 64-Kbyte Flash memory
20-byte backup data
Up to 8-Kbyte SRAM
HW parity checking
Connectivity
2x SPI
(1x with I²S mode )
HDMI CEC
2x I²C
(1x with fast-mode plus)
2x USART
with modem control
(1x with LIN, smartcard, IrDA)
