The STR7 is a range of innovative 32 bit microcontrollers built on the
industry standard ARM7 RISC core. The STR7 devices include high
quality embedded Flash and feature powerful peripheral functions
including USB and CAN. They are ideal for embedded applications
requiring a compact yet powerful MCU and a versatile scalable solution.
STR7 are used in various applications like user interfaces, factory
automation systems, point of sale, appliances and many others. Built on
the leading ARM™ architecture, STR7 allows fast response to emerging
requirements, enabling the rapid implementation of changes at low
cost. The flexibility of the family, with its rich options for Flash, RAM, the
largest peripherals set and its versatile package options helps you reuse
it for a whole range of products, optimizing your developments. It helps
you build cost effective and powerful solutions that bring innovation in
your market. ARM core with embedded Flash and RAM.
The STR71xF series is a family of ARM powered 16/32-bit Micro-
controllers with embedded Flash and RAM. It contains the high
performance ARM7TDMI CPU with an extensive range of peripheral
functions and enhanced I/O capabilities. All devices have on-chip
high speed single voltage FLASH memory and high speed RAM.
The STR71xF family has an embedded ARM core and is therefore
compatible with all ARM tools and software. For more information on the
ARM Realview Developer Kit for ST and third party development tools,
please refer to the www.st.com/mcu
STR730F Flash microcontrollers from STMicroelectronics combine the
industry standard ARM7TDMI® RISC microprocessor with embedded
Flash and powerful peripheral functions, including up to 20 timers,
4xUARTs and 3xCANs. They are ideal for embedded applications
requiring a compact yet powerful MCU, as well as versatile, scalable
solutions such as user interfaces, factory automation systems and
appliances. Additionally, the STR730F family features a single 5V
power supply particularly suited to industrial applications. Features:
High-performance industry standard core ARM7TDMI RISC 32-bit
CPU • Extensive software and tools including the complete STR7
library supporting all standard peripherals and the CAN • Largest
choice of peripherals and interfaces including 4xUARTs, up to 20
timers and up to 3xCANs • Flexible power and clock management,
five low-power modes, low-power voltage regulator, dual APB buses
architecture, multiple clock sources • Single 5V power supply • High-
quality embedded Flash (data retention 20 years at 85°C) • 16 x
channels DMA • Rich package options including the tiny proven 10x10
LFBGA144 • Temperature range: -40°C ~ 85°C and -40°C ~ 105°C
Benefits:Future-proof microcontrollers that easily adapt to customer
requirements • Dramatically reduces development time and increases
ease-of-use • Reduces system cost with all peripherals in one chip
Gives you full control over your power consumption and performance/
power trade-offs • Native supply of industrial applications. No 3.3V
conversion needed • Suitable for long-life equipment • Lower CPU
load, optimized access to memory • Optimizes your developments: the
same device in different options will fit all your product range • Increase
domain of validity for the application to +105°C
(Continued)
32-Bit ARM Microcontrollers and Tools
Internal Internal Internal Temperature Digi-Key Price Each Tape & Reel§ STMicroelectronics
ROM Type ROM Size RAM Size USB CAN I/O Ports Package Range Part No. 1 10 100 Qty. Pricing Part No.
128K 32K Yes Yes 48 144-TQFP -40°C ~ 85°C 497-4510-ND◆ 14.50 13.42 10.15 STR710FZ1T6
256K 64K Yes Yes 48 144-LFBGA -40°C ~ 85°C 497-5642-ND◆ 16.10 14.90 11.27 STR710FZ2H6
256K 64K Yes Yes 48 144-TQFP -40°C ~ 85°C 497-4511-ND◆ 16.10 14.90 11.27 STR710FZ2T6
64K 16K Yes No 30 64-TQFP -40°C ~ 85°C 497-4885-ND◆ 10.24 9.35 7.39 STR711FR0T6
128K 32K Yes No 30 64-TQFP -40°C ~ 85°C 497-4512-ND 11.50 10.64 8.05 STR711FR1T6
256K 64K Yes No 30 64-LFBGA -40°C ~ 85°C 497-5643-ND◆ 11.64 10.77 8.15 STR711FR2H6
256K 64K Yes No 30 64-TQFP -40°C ~ 85°C 497-4513-ND◆ 13.10 12.12 9.17 STR711FR2T6
64K 16K No Yes 32 64-TQFP -40°C ~ 85°C 497-4887-ND◆ 10.24 9.35 7.39 STR712FR0T6
128K 32K No Yes 32 64-TQFP -40°C ~ 85°C 497-4514-ND◆ 10.10 9.35 7.07 STR712FR1T6
256K 64K No Yes 32 64-TQFP -40°C ~ 85°C 497-4515-ND◆ 11.80 10.92 8.26 STR712FR2T6
64K 16K No No 32 64-TQFP -40°C ~ 85°C 497-4888-ND◆ 8.97 8.19 6.48 STR715FR0T6
256K 16K Yes Yes 112 144-LQFP -40°C ~ 105°C 497-5645-ND◆ 15.80 14.62 11.06 STR730FZ2T6
128K 16K Yes Yes 112 144-TQFP -40°C ~ 105°C 497-5139-ND◆ 17.46 16.16 12.23 STR730FZ1T7
256K 16K Yes Yes 112 144-LFBGA -40°C ~ 105°C 497-5644-ND◆ 15.80 14.62 11.06 STR730FZ2H6
256K 16K Yes Yes 112 144-TQFP -40°C ~ 105°C 497-5140-1-ND†◆ 19.74 18.26 13.82 360 4725.72 STR730FZ2T7
128K 16K Yes Yes 72 100-TQFP -40°C ~ 105°C 497-5141-1-ND†◆ 16.62 15.38 11.64 540 5699.16 STR731FV1T7
256K 16K Yes Yes 72 100-TQFP -40°C ~ 105°C 497-5142-ND◆ 18.70 17.30 13.09 STR731FV2T7
256K 16K Yes Yes 72 100-TQFP -40°C ~ 105°C 497-5646-ND◆ 14.96 13.84 10.48 STR731FV2T6
128K 16K Yes No 112 144-TQFP -40°C ~ 105°C 497-5143-1-ND†◆ 14.38 13.31 10.07 360 3442.68 STR735FZ1T7
256K 16K Yes No 112 144-LQFP -40°C ~ 105°C 497-5647-ND◆ 13.16 12.18 9.22 STR735FZ2T6
256K 16K Yes No 112 144-TQFP -40°C ~ 105°C 497-5144-1-ND†◆ 16.46 15.23 11.53 360 3940.56 STR735FZ2T7
128K 16K Yes No 72 100-TQFP -40°C ~ 105°C 497-5145-1-ND†◆ 14.60 13.51 10.22 540 5006.34 STR736FV1T7
256K 16K Yes No 72 100-TQFP -40°C ~ 105°C 497-5648-ND◆ 12.46 11.53 8.73 STR736FV2T6
256K 16K Yes No 72 100-TQFP -40°C ~ 105°C 497-5146-1-ND†◆ 15.58 14.42 10.91 540 5342.22 STR736FV2T7
256K 16K Yes Yes 72 100-LQFP -40°C ~ 105°C 497-5650-ND◆ 11.40 10.41 8.23 STR750FV2T6
Flash 64K 16K Yes Yes 72 100-LQFP -40°C ~ 85°C 497-5749-ND◆ 9.05 8.26 6.53 STR750FV0T6
128K 16K Yes Yes 72 100-LQFP -40°C ~ 85°C 497-5750-ND◆ 9.79 8.95 7.07 STR750FV1T6
256K 16K Yes Yes 72 100-LFBGA -40°C ~ 105°C 497-5649-ND◆ 11.40 10.41 8.23 STR750FV2H6
64K 16K Yes No 38 64-LQFP -40°C ~ 85°C 497-5755-ND◆ 8.78 8.02 6.34 STR751FR0T6
128K 16K Yes No 38 64-LQFP -40°C ~ 85°C 497-5756-ND◆ 9.53 8.71 6.88 STR751FR1T6
256K 16K Yes No 38 64-LFBGA -40°C ~ 105°C 497-5651-ND◆ 11.03 10.07 7.96 STR751FR2H6
256K 16K Yes No 38 64-LQFP -40°C ~ 105°C 497-5652-ND◆ 11.03 10.07 7.96 STR751FR2T6
256K 16K No Yes 38 64-LQFP -40°C ~ 105°C 497-5653-ND◆ 11.03 10.07 7.96 STR752FR2T6
256K 16K No No 38 64-LQFP -40°C ~ 105°C 497-5654-ND◆ 10.43 9.53 7.53 STR755FR2T6
64K 16K No No 72 100-LQFP -40°C ~ 85°C 497-5757-ND◆ 8.56 7.82 6.18 STR755FV0T6
128K 16K No No 72 100-LQFP -40°C ~ 85°C 497-5758-ND◆ 9.31 8.50 6.72 STR755FV1T6
256K 16K No No 72 100-LFBGA -40°C ~ 85°C 497-5871-ND◆ 10.80 9.87 7.80 STR755FV2H6
256K 16K No No 72 100-LQFP -40°C ~ 85°C 497-5759-ND◆ 10.80 9.87 7.80 STR755FV2T6
256K 64K No Yes 40 80-LQFP -40°C ~ 80°C 497-6275-ND◆ NEW! 10.37 9.60 7.27 STR910FAM32X6
256K 64K No Yes 80 128-LQFP -40°C ~ 80°C 497-6276-ND◆ NEW! 11.02 10.20 7.72 STR910FAW32X6
256K 64K No Yes 80 144-LFBGA -40°C ~ 80°C 497-6277-ND◆ NEW! 11.54 10.68 8.08 STR910FAZ32H6
256K 96K Yes Yes 40 80-LQFP -40°C ~ 80°C 497-6278-ND◆ NEW! 11.15 10.32 7.81 STR911FAM42X6
512K 96K Yes Yes 40 80-LQFP -40°C ~ 80°C 497-6279-ND◆ NEW! 12.45 11.52 8.72 STR911FAM44X6
256K 96K Yes Yes 80 128-LQFP -40°C ~ 80°C 497-6280-ND◆ NEW! 11.54 10.68 8.09 STR911FAW42X6
512K 96K Yes Yes 80 128-LQFP -40°C ~ 80°C 497-6281-ND◆ NEW! 13.10 12.13 9.18 STR911FAW44X6
256K 96K Yes Yes 80 128-LQFP -40°C ~ 80°C 497-6283-ND◆ NEW! 12.19 11.28 8.54 STR912FAW42X6
512K 96K Yes Yes 80 128-LQFP -40°C ~ 80°C 497-6284-ND◆ NEW! 14.40 13.33 10.09 STR912FAW44X6
256K 96K Yes Yes 80 144-LFBGA -40°C ~ 80°C 497-6285-ND◆ NEW! 12.72 11.77 8.91 STR912FAZ42H6
512K 96K Yes Yes 80 144-LFBGA -40°C ~ 80°C 497-6286-ND◆ NEW! 14.92 13.81 10.45 STR912FAZ44H6
128K 32K Yes Yes 80 48-LQFP -40°C ~ 80°C 497-6287-ND◆ NEW! 7.48 6.83 5.40 STM32F101CBT6
128K 32K Yes Yes 80 48-LQFP -40°C ~ 80°C 497-6288-ND◆ NEW! 8.83 8.07 6.38 STM32F103CBT6
RoHS Compliant § For Tape and Reel part number, change 1-ND to 2-ND. † Cut Tape
