Data Brief
For further information contact your local STMicroelectronics sales office.
October 2007 Rev 1 1/3
3
STM3210B-PFSTICK
Hitex STM32-PerformanceStick
complete tool package for STM32 evaluation and development
Features
■ HiTOP5 integrated development environment
with project manager, editor and high-level
language debugging
■ Tasking VX C/C++ compiler, no code size
limitations
■ STM32-PerformanceStick with STM32F103B
and:
– In-circuit debugging/programming via
dedicated USB connection to the host PC
– Connector for extension I/O boards
– Auxiliary power supply from 3V button
battery
■ Optional extension I/O board with features for
peripheral evaluation (USB, CAN, USART,
IrDA, ...)
■ DashBoard interface for modifying STM32
parameters and viewing performance
indicators
■ C source code for all sample applications and
libraries including:
– USB mouse
– Vectored interrupt controller and timer
– ADC and I/Os
– CAN monitor and generator
– STM32 library from STMicroelectronics
Description
The Hitex STM32-PerformanceStick is a
complete, low-cost evaluation and development
package that provides a fast and easy
introduction to the capabilities of ST’s ARM
®
Cortex™-M3 core-based STM32 family of
microcontrollers. It is specifically designed to help
application designers explore STM32 features
and performance characteristics (low power
modes, clock controls, wake up states, etc.), but
can also be connected to extension boards with
hardware features for evaluation of device
peripherals or development of an application.
The Hitex software toolset for STM32 includes
everything developers need to modify and rebuild
the sample applications (C sources included) and
to develop their own applications using the
STM32-PerformanceStick. The software includes
HiTOP5, Hitex’s integrated development
environment that drives the hardware and offers a
full range of project management, source code
editing and debugging features from an intuitive
graphical interface. For more information about
HiTOP5 downloads and updates, refer to the
Hitex website.
The software also includes the Altium Tasking VX
C compiler for compiling application source files.
When using the STM32-PerformanceStick, the
compiler has no output code-size limitations.
The DashBoard graphical interface allows users
to modify STM32 configuration and view
performance information. This is possible thanks
to the innovative hardware design of the STM32-
PerformanceStick, which retrieves STM32 and
peripheral performance information in real time.
www.st.com
