STM32F405ZGT6 其他数据使用手册 - ST Microelectronics（意法半导体）
制造商:
ST Microelectronics（意法半导体）
分类:
微控制器
封装:
LQFP-144
描述:
STM32F405/415，ARM® 32 位 Cortex™-M4 微控制器STMicroelectronics ARM Cortex **STM32 F405/415** 系列微控制器用于嵌入式应用。 高性能 **STM32** F4 系列 32 位闪存 MCU 提供浮点单元 (FPU) 和数字信号处理 (DSP)，带工业标准芯体系架构。 ST 32 位 ARM® Cortex™ M4 核心在 168 MHz 范围运行，带有集成外设，包括 ADC、DAC、计时器和为 AES 128、192、256、Triple DES 和 hash (MD5, SHA-1) 提供硬件加速的 crypto/hash 处理器（**仅 STM32F415）**。 ST ART 加速器和动态电源比例降低运行模式中的电流消耗。 USB OTG（高速支持） 音频：音频 PLL 和 2 个全双工 I²S 通信接口：USART、SPI、I²C、CAN、SDIO 模拟：12 位 DAC、12 位 ADC 计时器：16 位和 32 位 (168 MHz) 闪存：1 MB；SRAM：92 KB **仅 STM32F415：**集成 crypto/hash 处理器 模拟真随机编号发生器 工作电压：1.7 至 3.6 V 温度范围：-40 至 +85°C 或 -40 至 +105°C ### STM32F4 系列 32 位 ARM Cortex-M4 微控制器，STMicroelectronics基于 ARM Cortex-M4 的 STM32 F4 系列高性能 MCU，带有 DSP 和 FPU 指令，是行业领先的 STM32 组合向更高性能的扩展。 工作频率高达 180 MHz。多达 2 个 USB 2.0 OTG FS/HS SDIO（安全数字输入输出） USART、SPI、I²C I²S（内部 IC 声音）+ 音频 PLL 16 和 32 位计时器 多达 3 个 12 位 ADC 低电压 1.7 V 至 3.6 V展开
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
原理图在P4
功能描述在P4P5
应用领域在P3
导航目录
STM32F405ZGT6数据手册
Page:
of 14 Go
若手册格式错乱，请下载阅览PDF原文件
5
FEATURES AND BENEFITS
Features Benets
Designed for high performance and ultra-fast data transfers
• ART Accelerator™: memory accelerator
• Chrom‑ART Accelerator™: graphic accelerator (rectangle lling,
rectangle copy with pixel format conversion and blending)
• Performance equivalent to zero‑wait execution from Flash
• Graphic content is created twice as fast and independently from the
CPU
• 32‑bit, 7‑layer AHB bus matrix with up to 10 masters and 8 slaves
including 3 blocks of SRAM
• Multi DMA controllers: 2 general‑purpose, 1 for USB HS, one for
Ethernet
• Concurrent execution and data transfer
• One 4th SRAM block dedicated to the core • Simplied resource allocation
• Flexible memory interface with SDRAM support: up to 90 MHz,
32‑bit parallel
• High bandwidth for external memories
• Cost‑effective external RAM
Outstanding power efciency
• Ultra‑low dynamic power in Run mode: 140uA/MHz at 84 MHz
(STM32F401), 260 μA/MHz at 180 MHz (STM32F429/F439)
running CoreMark benchmark from Flash memory (peripherals off)
• RTC <1 μA typ in V
BAT
mode
• Down to 11 µA typ (STM32F401) 100 μA typ (STM32F429/439)
in Stop mode
• 3.6 V down to 1.7 V
1
V
DD
• 1.2 V voltage regulator with power scaling capability
• Extra exibility to reduce power consumption for applications
requiring both high‑processing and low‑power performance when
running at low voltage or on a rechargeable battery
Superior and innovative peripherals and connectivity
• Connectivity: camera interface, crypto/hash HW processor with AES
GCM and CCM support, and SHA‑256
• Ethernet MAC10/100 with IEEE 1588 v2 support, 2 USB OTG
(one with HS support)
• Up to 20 communication interfaces (including 4x USART + 4xUART,
6x SPI, 3x I²C with digital lter, 2x CAN, SDIO)
• USART at 11.25 Mbit/s; SPI at 45 Mbit/s
• New possibilities to connect and communicate high‑speed data
• Audio: dedicated audio PLL, 2x I²S and 1x SAI with TDM
2
support • High‑quality multi‑channel audio support
• LCD TFT controller
• Up to SVGA format (800 x 600)
• Up to 24‑bit RGB parallel pixel output
• 2‑layer support with blending
• Support for cost‑effective standard displays
• Analog: 2x 12‑bit DACs, 3x 12‑bit ADCs reaching 7.2 MSPS
in interleaved mode
• Up to 17 timers: 16 and 32 bits running up to 180 MHz
• More precision thanks to high resolution
High integration
• WLCSP49 3 x 3 mm (STM32F401, 256‑Kbyte Flash/64‑
Kbyte SRAM), WLCSP90 4 x 4.2 mm (STM32F405/F415,
1‑Mbyte Flash/192‑Kbyte SRAM), WLCSP143 4.5 x 5.5 mm
(STM32F429/439, 2‑Mbyte Flash/256‑Kbyte SRAM)
• Smaller board space allowing for smaller applications
Extensive tools and software solutions
• Hardware sector protection with execute only access,
• Various IDE, starter kits, libraries, RTOS and stacks, either open
source or provided by ST or 3rd parties, including the ARM CMSIS
DSP library optimized for Cortex‑M4 instructions
• Software IP protection
• A wide choice within the STM32 ecosystem to develop your
applications
Note:
1. Except LQFP64 and LQFP100 packages
2. TDM: time division multiplex
BRSTM32F40113.indd 5 29-Aug-13 16:44:37
