This is information on a product in full production.
December 2017 DocID028094 Rev 6 1/143
STM32F410x8 STM32F410xB
Arm
®
-Cortex
®
-M4 32b MCU+FPU, 125 DMIPS, 128KB Flash,
32KB RAM, 9 TIMs, 1 ADC, 1 DAC, 1 LPTIM, 9 comm. interfaces
Datasheet - production data
Features
Dynamic Efficiency Line with eBAM (enhanced
Batch Acquisition Mode)
1.7 V to 3.6 V power supply
-40 °C to 85/105/125 °C temperature range
Core: Arm
®
32-bit Cortex
®
-M4 CPU with FPU,
Adaptive real-time accelerator (ART
Accelerator™) allowing 0-wait state execution
from Flash memory, frequency up to 100 MHz,
memory protection unit,
125 DMIPS/1.25 DMIPS/MHz (Dhrystone 2.1),
and DSP instructions
Memories
Up to 128 Kbytes of Flash memory
512 bytes of OTP memory
32 Kbytes of SRAM
Clock, reset and supply management
1.7 V to 3.6 V application supply and I/Os
POR, PDR, PVD and BOR
4-to-26 MHz crystal oscillator
Internal 16 MHz factory-trimmed RC
32 kHz oscillator for RTC with calibration
Internal 32 kHz RC with calibration
Power consumption
Run: 89 µA/MHz (peripheral off)
Stop (Flash in Stop mode, fast wakeup
time): 40 µA Typ @ 25 °C; 49 µA max
@25 °C
Stop (Flash in Deep power down mode,
slow wakeup time): down to 6 µA @ 25 °C;
14 µA max @25 °C
Standby: 2.4 µA @25 °C / 1.7 V without
RTC; 12 µA @85 °C @1.7 V
–V
BAT
supply for RTC: 1 µA @25 °C
1×12-bit, 2.4 MSPS ADC: up to 16 channels
1×12-bit D/A converter
General-purpose DMA: 16-stream DMA
controllers with FIFOs and burst support
Up to 9 timers
One low-power timer (available in Stop
mode)
One 16-bit advanced motor-control timer
Three 16-bit general purpose timers
One 32-bit timer up to 100 MHz with up to
four IC/OC/PWM or pulse counter and
quadrature (incremental) encoder input
Two watchdog timers (independent
window)
SysTick timer.
Debug mode
Serial wire debug (SWD) & JTAG
interfaces
–Cortex
®
-M4 Embedded Trace Macrocell™
Up to 50 I/O ports with interrupt capability
Up to 45 fast I/Os up to 100 MHz
Up to 49 5 V-tolerant I/Os
Up to 9 communication interfaces
Up to 3x I
2
C interfaces (SMBus/PMBus)
including 1x I
2
C Fast-mode at 1 MHz
Up to 3 USARTs (2 x 12.5 Mbit/s,
1 x 6.25 Mbit/s), ISO 7816 interface, LIN,
IrDA, modem control)
Up to 3 SPI/I2Ss (up to 50 Mbit/s SPI or
I2S audio protocol)
True random number generator
CRC calculation unit
96-bit unique ID
RTC: subsecond accuracy, hardware calendar
All packages are ECOPACK
®
2
Table 1. Device summary
Reference Part number
STM32F410x8
STM32F410T8, STM32F410C8,
STM32F410R8
STM32F410xB
STM32F410TB, STM32F410CB,
STM32F410RB
WLCSP36
UFQFPN48
(7×7mm)
(2.553x2.579mm)
LQFP48 (7x7mm)
&"'!
UFBGA64
(
5x5mm
)
LQFP64 (10×10mm)
www.st.com
