For further information contact your local STMicroelectronics sales office.
September 2015 DocID028151 Rev 1 1/4
STM32479I-EVAL
Evaluation board with STM32F479NI MCU
Data brief
Features
STM32F479NIH6 microcontroller with
2 Mbytes of Flash memory and 324 Kbytes of
RAM in TFBGA package
six 5 V power supply options:
– power jack
– ST-LINK/V2-1 USB connector
– user USB HS connector
– user USB FS1 connector
– user USB FS2 connector
– daughterboard
SAI Audio DAC
stereo audio jack which supports headset with
microphone
stereo digital microphone
audio jack connector used to connect external
speakers
2-Gbyte (or more) SDMMC interface microSD
card
RF-EEPROM on I2C compatible serial
interface
RS232 communication
IrDA transceiver
JTAG/SWD and ETM trace debug support
embedded ST-LINK/V2-1
IEEE-802.3-2002 compliant Ethernet
connector
camera module
8Mx32 bit SDRAM, 1Mx16 bit SRAM and
8Mx16 bit NOR Flash
512-Mbit Quad-SPI NOR Flash
4-inch 800x480 pixel TFT color LCD with MIPI
DSI interface and capacitive touch panel
joystick with 4-direction control and selector
reset, WakeUp/Tamper or key button
4 color user LEDs
extension connectors and memory connectors
for daughterboard or wrapping board
USB OTG HS and FS with Micro-AB
connectors
1. Picture not contractual
RTC with backup battery
CAN2.0A/B compliant connection
potentiometer
motor control connector
www.st.com
