This is information on a product in full production.
March 2015 DocID022186 Rev 4 1/97
STM8S005C6 STM8S005K6
Value line, 16 MHz STM8S 8-bit MCU, 32 Kbytes Flash, data
EEPROM, 10-bit ADC, timers, UART, SPI, I²C
Datasheet - production data
Features
Core
Max f
CPU
: 16 MHz
Advanced STM8 core with Harvard
architecture and 3-stage pipeline
Extended instruction set
Memories
Medium-density Flash/EEPROM
– Program memory: 32 Kbytes of Flash
memory; data retention 20 years at 55 °C
after 100 cycles
– Data memory: 128 bytes true data
EEPROM; endurance up to 100 k
write/erase cycles
RAM: 2 Kbytes
Clock, reset and supply management
2.95 V to 5.5 operating voltage
Flexible clock control, 4 master clock sources
– Low-power crystal resonator oscillator
– External clock input
– Internal, user-trimmable 16 MHz RC
– Internal low-power 128 kHz RC
Clock security system with clock monitor
Power management
– Low-power modes (wait, active-halt, halt)
– Switch-off peripheral clocks individually
– Permanently active, low-consumption
power-on and power-down reset
Interrupt management
Nested interrupt controller with 32 interrupts
Up to 37 external interrupts on 6 vectors
Timers
2x 16-bit general purpose timers, with 2+3
CAPCOM channels (IC, OC or PWM)
Advanced control timer: 16-bit, 4 CAPCOM
channels, 3 complementary outputs, dead-time
insertion and flexible synchronization
8-bit basic timer with 8-bit prescaler
Auto wakeup timer
Window and independent watchdog timers
Communications interfaces
UART with clock output for synchronous
operation, SmartCard, IrDA, LIN
SPI interface up to 8 Mbit/s
I
2
C interface up to 400 Kbit/s
Analog to digital converter (ADC)
10-bit ADC, ± 1 LSB ADC with up to 10
multiplexed channels, scan mode and analog
watchdog
I/Os
Up to 38 I/Os on a 48-pin package including 16
high-sink outputs
Highly robust I/O design, immune against
current injection
Development support
Embedded single-wire interface module
(SWIM) for fast on-chip programming and non-
intrusive debugging
LQFP48
7 x 7mm
LQFP32
7 x 7mm
www.st.com
