– universal clip on heatsinks for type TO 218, TO 229, TO 247, TO 248, SIP-Muliwatt and similar
– easy assembly by pushing the heatsink onto the component
– for vertical and horizontal fastening by soldering
– fin height variations on request
– special design accord. to customized specification
art. no.
FK 245 MI 247 O
without soldering lug
art. no.
FK 245 MI 247 H
with soldering lug for horizontal mounting
art. no.
FK 245 MI 247 V
with soldering lug for vertical mounting
art. no.
FK 243 MI 247 O
without soldering lug
art. no.
FK 243 MI 247 H
with soldering lug for horizontal mounting
art. no.
FK 243 MI 247 V
with soldering lug for vertical mounting
copper (Cu)material:
0.6 mmmaterial thickness:
solderablesurface treatment:
H
HH
C 12
C 17
➔
Heatsinks for D PAKE 33
➔
Solder pins
C 2 – 3
➔
Finger-shaped heatsinksE 32
➔
Solder terminals
C 15 – 16
➔
Heatsinks for TO 5 and TO 18E 33
➔
Plugs
C 4 – 9
➔
Heatsinks for transistorsE 2 – 14
➔
Thermal conductive material
H
Hola1
H
Attachable heatsink
H
A
B
C
D
E
F
G
H
I
K
L
M
N
