NAND Flash Memory
SLC Small Block
Access Time Program/Erase Time (typ.)
Capacity Part Number
Page Size
(bit)
Block Size
(bit)
Serial cycle
(min) (ns)
1st access
(max) (µs)
Program Time
(ms)
Block Erase Time
(ms)
Power Supply
(V)
Operating
Temperature
(°C)
Package
512 Mbits TC58DVM92A5TA00 * (512 + 16) x 8 (16K + 512) x 8 40 25 0.3 2.5 2.7 to 3.6 0 to 70 TSOP I 48-P-1220-0.50
512 Mbits TC58DVM92A5BAJ3 * (512 + 16) x 8 (16K + 512) x 8 40 25 0.3 2.5 2.7 to 3.6 −40 to 85 P-TFBGA63-0813-0.80AZ
1 Gbits TC58DVG02A5TA00 * (512 + 16) x 8 (16K + 512) x 8 40 25 0.3 2.5 2.7 to 3.6 0 to 70 TSOP I 48-P-1220-0.50
1 Gbits TC58DVG02A5BAJ4 * (512 + 16) x 8 (16K + 512) x 8 40 25 0.3 2.5 2.7 to 3.6 −40 to 85 P-TFBGA63-0911-0.80CZ
• Contact the Toshiba sales representative for information about RoHS compliance before you purchase any components. *: New product
SLC Large Block Middle Capacity
Access Time Program/Erase Time (typ.)
Capacity Part Number
Page Size
(bit)
Block Size
(bit)
Serial cycle
(min) (ns)
1st access
(max) (µs)
Program Time
(ms)
Block Erase Time
(ms)
Power
Supply
(V)
Operating
Temperature
(°C)
Package
512 Mbits TC58NVM9S3ETA00 * (2048 + 64) x 8 (128K + 4K) x 8 25 30 0.3 2.5 2.7 to 3.6 0 to 70 TSOP I 48-P-1220-0.50
512 Mbits TC58NVM9S3EBAI3 * (2048 + 64) x 8 (128K + 4K) x 8 25 30 0.3 2.5 2.7 to 3.6 −40 to 85 P-TFBGA63-0813-0.80AZ
1 Gbits TC58NVG0S3ETA00 (2048 + 64) x 8 (128K + 4K) x 8 25 30 0.3 2.5 2.7 to 3.6 0 to 70 TSOP I 48-P-1220-0.50
1 Gbits TC58NVG0S3EBAI4 (2048 + 64) x 8 (128K + 4K) x 8 25 30 0.3 2.5 2.7 to 3.6 −40 to 85 P-TFBGA63-0911-0.80CZ
2 Gbits TC58NVG1S3ETA00 (2048 + 64) x 8 (128K + 4K) x 8 25 30 0.3 2.5 2.7 to 3.6 0 to 70 TSOP I 48-P-1220-0.50
2 Gbits TC58NVG1S3EBAI5 (2048 + 64) x 8 (128K + 4K) x 8 25 30 0.3 2.5 2.7 to 3.6 −40 to 85 P-TFBGA63-1013-0.80AZ
4 Gbits TC58NVG2S3ETA00 (2048 + 64) x 8 (128K + 4K) x 8 25 30 0.3 2.5 2.7 to 3.6 0 to 70 TSOP I 48-P-1220-0.50
4 Gbits TC58NVG2S3EBAI5 (2048 + 64) x 8 (128K + 4K) x 8 25 30 0.3 2.5 2.7 to 3.6 −40 to 85 P-TFBGA63-1013-0.80AZ
• Contact the Toshiba sales representative for information about RoHS compliance before you purchase any components. *: New product
SLC Large Capacity
Access Time Program/Erase Time (typ.)
Capacity Part Number
Page Size
(bit)
Block Size
(bit)
Serial cycle
(min) (ns)
1st access
(max) (µs)
Program Time
(ms)
Block Erase Time
(ms)
Power Supply
(V)
Operating
Temperature
(°C)
Package
8 Gbits TC58DVG3S0ETA00 * (4096 + 218) x 8 (256K + 13.6K) x 8 25 30 0.4 3 2.7 to 3.6 0 to 70 TSOP I 48-P-1220-0.50
16 Gbits TH58DVG4S0ETA20 * (4096 + 218) x 8 (256K + 13.6K) x 8 25 30 0.4 3 2.7 to 3.6 0 to 70 TSOP I 48-P-1220-0.50
32 Gbits TH58DVG5S0ETA20 * (4096 + 218) x 8 (256K + 13.6K) x 8 25 30 0.4 3 2.7 to 3.6 0 to 70 TSOP I 48-P-1220-0.50
• Contact the Toshiba sales representative for information about RoHS compliance before you purchase any components. *: New product
2 2010/9 SCE0004K
