1. General description
The TDA8566 is an integrated class-B output amplifier which is available in several
packages. TDA8566TH is contained in a 20-lead small outline plastic package. The
TDA8566TH1 is a 24-lead small outline plastic package which is pin compatible with the
I
2
C-bus controlled amplifier TDA1566TH for one board layout. TDA8566Q is a 17-pin
DIL-bent-SIL package.
The device contains 2 amplifiers in a Bridge-Tied Load (BTL) configuration. The output
power is 2 × 25 W in a 4 Ω load or 2 × 40 W in a 2 Ω load. It has a differential input stage
and 2 diagnostic outputs. The device is primarily developed for car radio applications.
2. Features
n Differential inputs
n Very high Common Mode Rejection Ratio (CMRR)
n High common mode input signal handling
n Requires very few external components
n High output power
n 4 Ω and 2 Ω load driving capability
n Low offset voltage at output
n Fixed gain
n Diagnostic facility (distortion, short-circuit and temperature pre-warning)
n Good ripple rejection
n Mode select switch (operating, mute and standby)
n Load dump protection
n Short-circuit proof to ground, to V
P
and across the load
n Low power dissipation in any short-circuit condition
n Thermally protected
n Reverse polarity safe
n Protected against electrostatic discharge
n No switch-on/switch-off plops
n Low thermal resistance
n TDA8566TH1 is pin compatible with TDA1566TH
TDA8566
2 × 40 W/2 Ω stereo BTL car radio power amplifier with
differential inputs and diagnostic outputs
Rev. 06 — 15 October 2007 Product data sheet
