3-Volt Advanced+ Boot Block Flash
Memory
28F800C3, 28F160C3, 28F320C3, 28F640C3 (x16)
Datasheet
Product Features
The 3-Volt Advanced+ Book Block Flash memory, manufactured on Intel’s latest 0.13 µmand
0.18 µm technologies, represents a feature-rich solution for low-power applications. 3-Volt
Advanced+ Boot Block Flash memory devices incorporate low-voltage capability (2.7 V read,
program, and erase) with high-speed, low-power operation. Flexible block locking allows any
block to be independently locked or unlocked. Add to this the Intel
®
Flash Data Integrator (IFDI)
software and you have a cost-effecive, flexible, monolithic code plus data storage solution. Intel
®
3-Volt Advanced+ Boot Block products will be available in 48-lead TSOP, 48-ball CSP, and 64-
ball Easy BGA packages. Additional information on this product family can be obtained by
accessing the Intel
®
Flash website: http://www.intel.com/design/flash.
■ Flexible SmartVoltage Technology
—2.7 V–3.6 V Read/Program/Erase
—12 V for Fast Production Programming
■ 1.65 V–2.5 V or 2.7 V–3.6 V I/O Option
—Reduces Overall System Power
■ High Performance
—2.7 V–3.6 V: 70 ns Max Access Time
■ Optimized Architecture for Code Plus Data
Storage
—Eight 4-Kword Blocks, Top or Bottom
Locations
—Up to One Hundred-Twenty-Seven 32-
Kword Blocks
—Fast Program Suspend Capability
—Fast Erase Suspend Capability
■ Flexible Block Locking
—Lock/Unlock Any Block
—Full Protection on Power-Up
—WP# Pin for Hardware Block Protection
—V
PP
= GND Option
—V
CC
Lockout Voltage
■ Low Power Consumption
—9 mA Typical Read Power
—7 µA Typical Standby Power with
Automatic Power Savings Feature
■ 12 V Fast Production Program
■ Extended Temperature Operation
—–40 °C to +85 °C
■ 128-bit Protection Register
—64-bit Unique Device Identifier
—64-bit User Programmable OTP Cells
■ Extended Cycling Capability
—Minimum 100,000 Block Erase Cycles
■ Supports Intel
®
Flash Data Integrator
Software
—Flash Memory Manager
—System Interrupt Manager
—Supports Parameter Storage, Streaming
Data (e.g., voice)
■ Automated Word/Byte Program and Block
Erase
—Command User Interface
—Status Registers
■ Cross-Compatible Command Support
—Intel Basic Command Set
—Common Flash Interface
■ Standard Surface Mount Packaging
—48-Ball CSP Packages
—64-Ball Easy BGA Packages
—48-Lead TSOP Package
■ ETOX™ VIII (0.13 µm) Flash Technology
—16-, 32-Mbit
■ ETOX™ VII (0.18 µm) Flash Technology
—16-, 32-, 64-Mbit
■ ETOX™ VI (0.25 µm) Flash Technology
—8-, 16- and 32-Mbit
Order Number: 290645-014
April 2002
Notice: This specification is subject to change without notice. Verify with your local Intel sales
office that you have the latest datasheet before finalizing a design.
