TIL111M, TIL117M, MOC8100M — General Purpose 6-Pin Phototransistor Optocouplers
©2005 Fairchild Semiconductor Corporation www.fairchildsemi.com
TIL111M, TIL117M, MOC8100M Rev. 1.0.3
May 2013
TIL111M, TIL117M, MOC8100M
General Purpose 6-Pin Phototransistor Optocouplers
Features
■
UL Recognized (File # E90700)
■
VDE Recognized (File #102497 for white package)
– Add Option V (e.g., TIL111VM)
Applications
■
Power Supply Regulators
■
Digital Logic Inputs
■
Microprocessor Inputs
■
Appliance Sensor Systems
■
Industrial Controls
General Description
The MOC8100M, TIL111M, and TIL117M optocouplers
consist of a gallium arsenide infrared emitting diode
driving a silicon phototransistor in a 6-pin dual in-line
package.
Schematic Package Outlines
CATHODE 2
NC 3
ANODE 1
5 COLLECTOR
6 BASE
4 EMITTER
Figure 1. Schematic
Figure 2. Package Outlines
