TIP100, TIP101, TIP102
Silicon NPN Darlington Power Amp, Switch
TO−220 Type Package
Absolute Maximum Ratings: (T
A
= +25C, Note 1 unless otherwise specified)
Collector−Base Voltage, V
CBO
TIP100 60V......................................................................
TIP101 80V......................................................................
TIP102 100V.....................................................................
Collector−Emitter Voltage, V
CEO
TIP100 60V......................................................................
TIP101 80V......................................................................
TIP102 100V.....................................................................
Emitter−Base Voltage, V
EBO
5V..........................................................
Collector Current, I
C
DC 5A..........................................................................
Pulse 8A........................................................................
Base Current, I
B
1A....................................................................
Collector Dissipation, P
C
T
A
= +25C 2W..................................................................
T
C
= +25C 80W.................................................................
Operating Junction Temperature, T
J
+150C...............................................
Storage Temperature Range, T
stg
−65 to +150C..........................................
Note 1. These ratings are limiting values above which the serviceability of any semiconductor device
may be impaired.
Electrical Characteristics: (T
A
= +25C, Note 2 unless otherwise specified)
Parameter Symbol Test Conditions Min Typ Max Unit
Collector−Emitter Sustaining Voltage
TIP100
V
CEO(sus)
I
C
= 30mA, I
B
= 0 60 − − V
TIP101 80 − − V
TIP102 100 − − V
Collector Cutoff Current
TIP100
I
CEO
V
CE
= 30V, I
B
= 0 − − 50 A
TIP101 V
CE
= 40V, I
B
= 0 − − 50 A
TIP102 V
CE
= 50V, I
B
= 0 − − 50 A
TIP100 I
CBO
V
CE
= 60V, I
B
= 0 − − 50 A
TIP101 V
CE
= 80V, I
B
= 0 − − 50 A
TIP102 V
CE
= 100V, I
B
= 0 − − 50 A
Note 2. Pulse Test: Pulse Width 300s, Duty Cycle 2%.
