TIP142TTU数据手册

Page:

of 25 Go

PDF下载

若手册格式错乱，请下载阅览PDF原文件

Final Product/Process Change Notification

Document #:FPCN22647XX

Issue Date:09 Apr 2020

NOTE: Fortheperiodof10/1/2019through1/10/2020,duetoadatairregularityinthecustomerimpactlists,someindirectsalescustomersmay

nothavereceivedproductchange,productdiscontinuance,orproductbulletinnoticesasexpectedthroughemail.Althoughthesenotificationswere

published on our public portal (https://www.onsemi.com/PowerSolutions/pcnPub.do), ON Semiconductor is taking the action to redistribute

affectednotices,withrevisedimplementationdatesconformingtoexternalstandardsandONSemiconductor’scustomernotificationpolicies.This

issuehasbeenresolved.QuestionsrelatedtothisissuecanbedirectedtoPCN.Support@onsemi.com

TEM001793 Rev. C Page 1 of 10

TitleofChange:

RedistributionofFPCN22647XJ(1stSplit)‐MoldCompoundChangeattributedtoanEndofLifeof

SamsungSDIEMCforproductsinTO‐220package.

ProposedFirstShipdate:

16Jul2020orearlierifapprovedbycustomer

ContactInformation:

ContactyourlocalONSemiconductorSalesOfficeorPCN.Support@onsemi.com

PCNSamplesContact:

ContactyourlocalONSemiconductorSalesOfficeorPCN.samples@onsemi.com;

<Bokyun.Seo@onsemi.com>;<Sariman.T@onsemi.com>;<JinMan.Song@onsemi.com>;

<David.Zhu@onsemi.com>;<Raja.Roziah.Rahmat@onsemi.com>;<CheePin.Tay@onsemi.com>;

<Khairil.FK@onsemi.com>

Samplerequestsaretobesubmittednolaterthan30daysfromthedateoffirstnotification,

InitialPCNorFinalPCN,forthischange.

Samplesdeliverytimingwillbesubjecttorequestdate,samplequantityandspecialcustomer

packing/labelrequirements.

AdditionalReliabilityData:

ContactyourlocalONSemiconductorSalesOfficeorLake.Wang@onsemi.com

TypeofNotification:

ThisisaFinalProduct/ProcessChangeNotification(FPCN)senttocustomers.FPCNsareissued90

dayspriortoimplementationofthechange.

ONSemiconductorwillconsiderthischangeaccepted,unlessaninquiryismadeinwritingwithin

30daysofdeliveryofthisnotice.Todoso,contactPCN.Support@onsemi.com

MarkingofParts/Traceabilityof

Change:

Productwithdatecode1949ornewerwillbeassembledwiththenewmoldcompound.

ChangeCategory:

AssemblyChange

ChangeSub‐Category(s):

MaterialChange

SitesAffected:

ONSemiconductorSites ExternalFoundry/SubconSites

ONSemiconductorSuzhou,China None

DescriptionandPurpose:



ONSemiconductorwishestoinformourcustomersofachangeinmoldcompoundsusedforthedeviceslistedinthisPCN.Thischangeisaresult

ofanEndofLifenotificationreceivedfromSamsungforseveraloftheirSDIMoldCompounds.



DuetothediscontinuanceoftheSDImold compounds, ON Semiconductorwill onlyhavelimitedsupplies of theexistingmaterialandinsome

casesthismaynotallowforthenormalchangenotificationperiod.



Allotheraspectsoftheimpactedproducts(form,fit,function)willremainunchanged.



 BeforeChangeDescription AfterChangeDescription

MoldCompound SI7200DX2;Supplier:SamsungSDI KTMC1050GFB,Supplier:KCC

MoldCompound SG8200DL;Supplier:SamsungSDI KTMC1050GFB,Supplier:KCC





1
2
3
4
5
•••
25
