TJA1044 All information provided in this document is subject to legal disclaimers. © NXP Semiconductors N.V. 2017. All rights reserved.
Product data sheet Rev. 6 — 24 August 2017 2 of 27
NXP Semiconductors
TJA1044
High-speed CAN transceiver with Standby mode
V
IO
input on TJA1044x/3 variants allows for direct interfacing with 3 V to 5 V
microcontrollers. Variants without a V
IO
pin can interface with 3.3 V and 5 V-supplied
microcontrollers, provided the microcontroller I/Os are 5 V tolerant.
Both V
IO
and non-V
IO
variants are available in SO8 and leadless HVSON8 (3.0
mm 3.0 mm) packages; HVSON8 with improved Automated Optical Inspection (AOI)
capability.
2.2 Predictable and fail-safe behavior
Functional behavior predictable under all supply conditions
Transceiver disengages from bus when not powered (zero load)
Transmit Data (TXD) and bus dominant time-out functions
Internal biasing of TXD and STB input pins
2.3 Protection
High ESD handling capability on the bus pins (8 kV IEC and HBM)
Bus pins protected against transients in automotive environments
Undervoltage detection on pins V
CC
and V
IO
Thermally protected
2.4 TJA1044 CAN FD (applicable to all product variants except TJA1044T)
Timing guaranteed for CAN FD data rates up to 5 Mbit/s
Improved TXD to RXD propagation delay of 210 ns
