Texas Instruments, Inc. PCN#20150904001A
PCN Number:
20150904001A
PCN Date:
03/15/2016
Title:
Carrier Tape Change for Selected SC70 Packaged Devices
Customer Contact:
PCN Manager
Dept:
Quality Services
Proposed 1
st
Ship Date:
12/08/2015
Change Type:
Assembly Site
Assembly Process
Assembly Materials
Design
Electrical Specification
Mechanical Specification
Test Site
Packing/Shipping/Labeling
Test Process
Wafer Bump Site
Wafer Bump Material
Wafer Bump Process
Wafer Fab Site
Wafer Fab Materials
Wafer Fab Process
Part number change
PCN Details
Description of Change:
Revision A is to announce the retraction of select devices. These devices will continue to be
packed in with the same carrier tape and not be subjected to the change described in this
notification. Affected devices are identified with a strikethrough and are highlighted in yellow
in the Product Affected Section.
Texas Instruments is pleased to announce the qualification of a new carrier tape for selected
devices in the SC70 package. The material composition between the 2 carrier tapes is the same.
A dimensional comparison summary is below:
Dimension
From
To
Ao
2.25 (+/- 0.1) mm
2.33 (+/- 0.1) mm
Bo
2.40 (+/- 0.1) mm
2.53 (+/- 0.1) mm
Ko
1.22 (+/- 0.1) mm
1.13 (+/- 0.1) mm
New Carrier tape Dimensions:
