TMP275
ZHCSA58E –JUNE 2006–REVISED NOVEMBER 2015
www.ti.com.cn
Copyright © 2006–2015, Texas Instruments Incorporated
(1) Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings
only, which do not imply functional operation of the device at these or any other conditions beyond those indicated under Recommended
Operating Conditions. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
(2) JEDEC document JEP157 states that 250-V CDM allows safe manufacturing with a standard ESD control process.
6 Specifications
6.1 Absolute Maximum Ratings
over operating free-air temperature range (unless otherwise noted)
(1)
MIN MAX UNIT
Power supply, V+ 7 V
Input voltage
(2)
–0.5 7 V
Input current 10 mA
Operating temperature –55 127 °C
Junction temperature, T
J
max, 150 °C
Storage temperature, T
stg
–60 130 °C
(1) JEDEC document JEP155 states that 500-V HBM allows safe manufacturing with a standard ESD control process.
(2) JEDEC document JEP157 states that 250-V CDM allows safe manufacturing with a standard ESD control process.
6.2 ESD Ratings
VALUE UNIT
V
(ESD)
Electrostatic
discharge
Human body model (HBM), per ANSI/ESDA/JEDEC JS-001, all pins
(1)
±4000
VCharged device model (CDM), per JEDEC specification JESD22-C101, all pins
(2)
±1000
Machine Model (MM) ±300
6.3 Recommended Operating Conditions
over operating free-air temperature range (unless otherwise noted)
MIN NOM MAX UNIT
Supply voltage 2.7 5.5 V
Operating free-air temperature, T
A
–40 125 °C
(1) For more information about traditional and new thermal metrics, see the Semiconductor and IC Package Thermal Metrics application
report, SPRA953.
6.4 Thermal Information
THERMAL METRIC
(1)
TMP275
UNITD (SOIC) AND DGK (VSSOP)
8 PINS
R
θJA
Junction-to-ambient thermal resistance 120 °C/W
R
θJC(top)
Junction-to-case (top) thermal resistance 66.7 °C/W
R
θJB
Junction-to-board thermal resistance 60.4 °C/W
ψ
JT
Junction-to-top characterization parameter 17.8 °C/W
ψ
JB
Junction-to-board characterization parameter 59.9 °C/W
R
θJC(bot)
Junction-to-case (bottom) thermal resistance N/A °C/W
