TMS320C5535 eZdsp
™
USB Development Kit
Key features and benefi ts
•
Small form factor DSP development kit for
the C5535 processor
• TMS320C5535 fi xed-point ultra-low-power
DSP
• Embedded XDS100 emulator
• 8-MB serial Flash memory
• TLV320AIC3204 programmable low-power
stereo audio codec
• USB 2.0 high speed
• Micro SD card slot with 2-GB micro SD card
• Line in/Mic in, headphone out audio jacks
• Earphone with mic
• 60-pin expansion connector
• 96 × 16-pixel OLED display
• Two push buttons
• Includes Code Composer Studio™ IDE 4.0
• Software framework for USB audio class
and HID applications
• Out-of-the-box demo software
• Full documentation with source code on
CD-ROM
Development Environment (IDE) version 4.0
and eXpressDSP™ software which includes
the DSP/BIOS™ kernel. The full contents of the
Development Kit include C5535 eZdsp board,
CCStudio IDE Rev. 4.0, a headphone with
mic, a 2-GB micro SD card, a free software
framework for USB audio class and human
interface device (HID) applications and an out-
of-the-box comprehensive demo for USB audio
class applications.
Technical details
The C5535 eZdsp USB kit simplifi es
development by providing integrated features
including:
• Complete Code Composer Studio v4 IDE for
fast code development
• On-board XDS100 v2 emulator provides
complete debugging capabilities and visibility
inside the processor for algorithm optimization
and benchmarking
• On-board audio codec and connectors allow
developers to evaluate the C5535 processor
and quickly optimize complex DSP algorithms in
terms of performance and power consumption
across a variety of design scenarios
• Energy-effi cient C5535 DSP allows the
entire development tool to be powered by
the USB port – no other components or
cables are needed
• Rich set of features including LCD 96 × 16
monochrome OLED display screen, MicroSD
card slot, USB 2.0 port for applications,
Bluetooth
®
/Chipcon expansion connector
Software
Designers can readily target the
TMS320C5532/33/34/35 DSP through TI’s
robust and comprehensive Code Composer
Studio IDE, including:
• A complete Integrated Development
Environment, an effi cient optimizing C/
C++ compiler assembler, linker, debugger,
integrated CodeWright editor with CodeSense
technology for faster code creation, data
visualization, a profi ler and a fl exible project
manager
• DSP/BIOS™ real-time kernel
• Chip Support Library
• Free, integrated software framework for USB
audio class and HID applications, including an
out-of-the-box demo
Community support
The eZdsp USB kit is supported by TI’s online
community e2e.ti.com. Complete collateral,
CCStudio IDE drivers, Chip Support Library
(CSL) and all the required production-quality
The TMDX5535eZdsp is a small form factor,
very-low-cost USB-powered DSP development
kit which includes hardware and software
needed to evaluate the C553x generation,
which is the industry’s lowest-cost and
lowest-power 16-bit DSP. This ultra-low-cost
kit allows quick and easy evaluation of the
advanced capabilities of the C5532, C5533,
C5534 and C5535 processors. The kit has an
on-board XDS100 emulator for full source-
level debug capability and supports Code
Composer Studio™ (CCStudio) Integrated
