Silicon Errata
SPRZ295M–April 2009–Revised November 2015
TMS320F2803x Piccolo™ MCU Silicon Errata
1 Introduction
This document describes the silicon updates to the functional specifications for the TMS320F2803x
microcontrollers (MCUs).
The updates are applicable to:
• 56-pin Plastic Quad Flatpack, RSH Suffix
• 64-pin Thin Quad Flatpack, PAG Suffix
• 80-pin Low-Profile Quad Flatpack, PN Suffix
2 Device and Development Support Tool Nomenclature
To designate the stages in the product development cycle, TI assigns prefixes to the part numbers of all
[TMS320] DSP devices and support tools. Each TMS320™ DSP commercial family member has one of
three prefixes: TMX, TMP, or TMS (for example, TMS320F28035). Texas Instruments recommends two of
three possible prefix designators for its support tools: TMDX and TMDS. These prefixes represent
evolutionary stages of product development from engineering prototypes (TMX/TMDX) through fully
qualified production devices/tools (TMS/TMDS).
TMX Experimental device that is not necessarily representative of the final device's electrical
specifications
TMP Final silicon die that conforms to the device's electrical specifications but has not
completed quality and reliability verification
TMS Fully qualified production device
Support tool development evolutionary flow:
TMDX Development-support product that has not yet completed Texas Instruments internal
qualification testing
TMDS Fully qualified development-support product
TMX and TMP devices and TMDX development-support tools are shipped against the following
disclaimer:
"Developmental product is intended for internal evaluation purposes."
TMS devices and TMDS development-support tools have been characterized fully, and the quality and
reliability of the device have been demonstrated fully. TI's standard warranty applies.
Predictions show that prototype devices (TMX or TMP) have a greater failure rate than the standard
production devices. Texas Instruments recommends that these devices not be used in any production
system because their expected end-use failure rate still is undefined. Only qualified production devices are
to be used.
TI device nomenclature also includes a suffix with the device family name. This suffix indicates the
package type (for example, PN) and temperature range (for example, T).
Piccolo, TMS320 are trademarks of Texas Instruments.
All other trademarks are the property of their respective owners.
4
TMS320F2803x Piccolo™ MCU Silicon Errata SPRZ295M–April 2009–Revised November 2015
Submit Documentation Feedback
Copyright © 2009–2015, Texas Instruments Incorporated
