TMS320F28030, TMS320F28031, TMS320F28032
TMS320F28033, TMS320F28034, TMS320F28035
www.ti.com
SPRS584E–APRIL 2009– REVISED MARCH 2011
Piccolo Microcontrollers
Check for Samples: TMS320F28030, TMS320F28031, TMS320F28032, TMS320F28033, TMS320F28034, TMS320F28035
1 TMS320F2803x ( Piccolo™) MCUs
1.1 Features
123
– No Power Sequencing Requirement
• Highlights
– Integrated Power-on Reset and Brown-out
– High-Efficiency 32-Bit CPU ( TMS320C28x™)
Reset
– 60-MHz Device
– Low Power
– Single 3.3-V Supply
– No Analog Support Pins
– Integrated Power-on and Brown-out Resets
• Clocking:
– Two Internal Zero-pin Oscillators
– Two Internal Zero-pin Oscillators
– Up to 45 Multiplexed GPIO Pins
– On-Chip Crystal Oscillator/External Clock
– Three 32-Bit CPU Timers
Input
– On-Chip Flash, SARAM, OTP Memory
– Dynamic PLL Ratio Changes Supported
– Code-Security Module
– Watchdog Timer Module
– Serial Port Peripherals
– Missing Clock Detection Circuitry
(SCI/SPI/I2C/LIN/eCAN)
• Up to 45 Individually Programmable,
– Enhanced Control Peripherals
Multiplexed GPIO Pins With Input Filtering
• Enhanced Pulse Width Modulator (ePWM)
• Peripheral Interrupt Expansion (PIE) Block That
• High-Resolution PWM (HRPWM)
Supports All Peripheral Interrupts
• Enhanced Capture (eCAP)
• Three 32-Bit CPU Timers
• Enhanced Quadrature Encoder Pulse
• Independent 16-Bit Timer in Each ePWM
(eQEP)
Module
• Analog-to-Digital Converter (ADC)
• On-Chip Memory
• On-Chip Temperature Sensor
– Flash, SARAM, OTP, Boot ROM Available
• Comparator
• 128-Bit Security Key/Lock
– 56-Pin, 64-Pin, and 80-Pin Packages
– Protects Secure Memory Blocks
• High-Efficiency 32-Bit CPU ( TMS320C28x™)
– Prevents Firmware Reverse Engineering
– 60 MHz (16.67-ns Cycle Time)
• Serial Port Peripherals
– 16 x 16 and 32 x 32 MAC Operations
– One SCI (UART) Module
– 16 x 16 Dual MAC
– Two SPI Modules
– Harvard Bus Architecture
– One Inter-Integrated-Circuit (I2C) Bus
– Atomic Operations
– One Local Interconnect Network (LIN) Bus
– Fast Interrupt Response and Processing
– One Enhanced Controller Area Network
– Unified Memory Programming Model
(eCAN) Bus
– Code-Efficient (in C/C++ and Assembly)
• Advanced Emulation Features
• Programmable Control Law Accelerator (CLA)
– Analysis and Breakpoint Functions
– 32-Bit Floating-Point Math Accelerator
– Real-Time Debug via Hardware
– Executes Code Independently of the Main
• 2803x Packages
CPU
– 56-Pin RSH Plastic Quad Flatpack (PQFP)
• Low Device and System Cost:
– 64-Pin PAG Thin Quad Flatpack (TQFP)
– Single 3.3-V Supply
– 80-Pin PN Low-Profile Quad Flatpack (LQFP)
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2Piccolo, TMS320C28x, C28x, TMS320C2000, Code Composer Studio, XDS510, XDS560 are trademarks of Texas Instruments.
3All other trademarks are the property of their respective owners.
UNLESS OTHERWISE NOTED this document contains
Copyright © 2009–2011, Texas Instruments Incorporated
PRODUCTION DATA information current as of publication date.
Products conform to specifications per the terms of Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
