All Prices are in US Dollars!
Toll-Free: 10800-1527031 (China Telecom -
፩࣭ݢᅹ
)
—
10800-8527031 (CNCG -
፩࣭၃
)
digikey.com.cn —
Telephone: (852) 3104 0500
—
Fax: (852) 3104 0686670
(CN081)
C
Digi-Key Price Texas Instruments
Part No. Each Part No.
296-15828-ND 358.25 TMDSEZD2407
296-15827-ND 410.17 TMDSDSK5510
296-15829-ND 410.17 TMDSDSK5416
296-15831-ND 410.17 TMDSDSK6713
A wide variety of DSP boards and development kits are available from TI and TI's third party network. Products include development boards, evaluation modules, hardware/
software bundles and DSP Starter Kits (DSKs) designed to accelerate the application design process from concept through production. DSP Starter Kits are bundled with a
DSK-version of TI's Code Composer Studio Development Tools. These provide an excellent platform to evaluate TI DSP and development tools, quickly develop prototypes,
demos and proof-of-concept applications at a very affordable getting started price. Kit Contents: • Development Board • Parallel PC Cable • US Power Supply • CD-ROM
containing documentation and DSK version of Code Composer Studio (TMDSEZD2407: EzDSP version of Code Composer Studio)
DSP Starter Kits
Digi-Key Price Texas Instruments
Description Part No. Each Part No.
C6000 Code Composer Studio Software for 320C6X 296-16633-ND 4044.38 TMDSCCS6000-1
C5000 Code Composer Studio Software for 320C5X 296-16631-ND 4044.38 TMDSCCS5000-1
C2000 Code Composer Studio Software for 320C2X 296-16632-ND 514.01 TMDSCCS2000-1
eXpressDSP™ Code Composer Studio™
CCStudio’s comprehensive, integrated development environment brings complete build and debug tooling, world-class
compilers and industry unique analysis and visualization capabilities via JTAG Real-Time Data Exchange (RTDX) to
quickly find and fix problems. The real-time foundation provided by TI’s DSP/BIOS™ kernel, RTDX™ and TI’s simulation
capabilities, offers key features such as real-time analysis and advanced data and system visualization, which results in
the highest level of host/target integration in the DSP industry. In addition, CCStudio is engineered around an open plug-
in architecture that enables developers to integrate additional third-party plug-in tools to customize their development
environment for specific project requirements.
Includes: • C/C++ compiler, assembler and linker (code generation tools) with C++, UML, MATLAB and VAB support in
compiler CCStudio Key Features: • Integrated development environment with tightly integrated editor, debugger, visual
project management system, profiler and Probe Points™ • Advanced watch windows, local and global variable windows
and profiler capabilities • Update Advisor - live update capability for the latest tools, drivers and software
releases • Real-Time Data Exchange (RTDX) between host and target • Real-time analysis and data visualization tools
• File I/O Probe Points and graphical algorithm scope probes • In teractive profiling and advanced graphical signal analysis
• GEL function support for automation activities such as regression testing • Automated testing and customization via
scripting • Multi-processor debugging
Minimum System Requirements: • 233MHz or higher Pentium compatible CPU • 600MB of free hard disk space
• 64MB of RAM • SVGA (800 x 600) display • Internet Explorer (4.0 or later) or Netscape Navigator (4.7 or later) • Local
CD-ROM drive
Supported Operating Systems for Code Composer Studio: • Micro soft Windows 98 (SP1 and SE) • Micro soft Windows NT
(SP6) • Micro soft Windows 2000 (SP1 and SP2) • Microsoft Windows XP
TMS470 Family
The TMS470 is derived from the 32-bit ARM7TDMI
®
core. This industry standard architecture includes two instruction sets a 32-bit instructions for fast execution and 16-bit instructions for high code
density. It allows unlimited switching between instruction sets and also provides run time decompression. Typical applications include industrial systems, medical instrumentation, consumer electronics,
data processing and many other general purpose embedded applications.
◆ RoHS Compliant
Digital Signal Processors TMS320C2000™ Family (Cont.)
◆ RoHS Compliant Δ Cut Tape ◊ Tape and Reel
Digi-Key Price Texas Instruments
Part No. Each Part No.
296-18350-ND 49.38 5-6KINTERFACE
5-6K Interface Evaluation Module
The interface board consists of two signal conditioning sites, two serial EVM sites and a parallel EVM site. Three position
screw terminals J1 and J2 and two position screw terminals J6, J8, J9 and J11 provides access to a common power bus
routed to all sites. The 5-6K Interface board is intended to provide Data Converter customers with the greatest amount of
flexibility for the evaluation of Data Acquisition Products from Texas Instruments. It maintains a compatible interface with
the TMS320 Series (DSP).
Features: • Provides all necessary voltages for device under test • Bit clock for codecs • Flexible interface to popular TI
DSP’s • General codec requirements are addressed
Digi-Key Price Texas Instruments
Part No. Each Part No.
296-18418-ND 49.38 DAPSIGCNDBRDBPEVM
296-18419-ND 49.38 DAPSIGCNDBRDUNPEVM
The DAPSigCndBrdBPEVM can be used with Data Acquisition Products (DAPs), 5-6K Interface and C2000 Interface
boards. This signal conditioning board, provides up to eight single ended or four differential conditioning channels for
use with a wide selection of data converter evaluation boards. The DAPSigCndBrdBPEVM board has four dual supply
OPA2132 operational amplifiers that operate at +/- 15 volts. This is a circuit board that gives the designer the ability to
condition the input/output signal going to and from ADCs or DACs, through the use of bi-polar (OPA2132UA) amplifiers
in the conditioning circuits.
DAP Signal Conditioning Boards
Flash RAM ROM Boot ROM Operating
(16-Bit (16-Bit (16-Bit (16-Bit PWM Voltage (V) Frequency Temperature Digi-Key Price Each Texas Instruments
Word) Word) Word) Word) McBSP EMIF Timers Chan. SPI SCI CAN MIPS Core I/O (MHz) (°C) Package Part No. 1 25 100 Part No.
-40 ~ 85 128-LQFP 296-15987-5-ND◆ 20.78 19.39 18.01 TMS320F2810PBKA
64K 18K 1K 4K Y — 4 16 Y 2 Y 150 1.8 3.3 150
-40 ~ 125 128-LQFP 296-17277-ND◆ 26.33 24.57 22.82 TMS320F2810PBKQ
-40 ~ 85 128-LQFP 296-15988-5-ND◆ 22.13 20.65 19.18 TMS320F2811PBKA
-40 ~ 125 128-LQFP 296-17278-ND◆ 28.05 26.18 24.31 TMS320F2811PBKQ
-40 ~ 85 100-BGA 296-21878-ND 19.43 18.13 16.84 TMS320F2809GGMA
1K 4K — — 15 16 4 2 2 100 1.8 3.3 100 -40 ~ 85 100-LQFP 296-21879-ND◆ 19.43 18.13 16.84 TMS320F2809PZA
-40 ~ 85 100-BGA 296-21880-ND◆ 19.43 18.13 16.84 TMS320F2809ZGMA
128K 18K
-40 ~ 85 179-BGA 296-15989-5-ND 23.48 21.91 20.35 TMS320F2812GHHA
1K 4K Y Y 4 16 Y 2 Y 150 1.8 3.3 150 -40 ~ 125 179-BGA 296-17279-ND 29.85 27.86 25.87 TMS320F2812GHHQ
-40 ~ 125 176-LQFP 296-17280-ND◆ 29.85 27.86 25.87 TMS320F2812PGFQ
2K 4K Y Y 7 16 Y 2 Y 150 1.9 3.3 150
-40 ~ 85 179-BGA 296-18338-ND◆ 23.48 21.91 20.35 TMS320F2812ZHHA
-40 ~ 125 179-BGA 296-18339-ND◆ 25.88 24.15 22.43 TMS320F2812ZHHS
-40 ~ 85 128-LQFP 296-18916-ND◆ 15.24 13.73 12.17 TMS320R2811PBKA
32K 1K 8K Y — 7 1 Y 2 Y 150 1.8 3.3 150
-40 ~ 125 128-LQFP 296-18917-ND◆ 15.08 14.07 13.07 TMS320R2811PBKQ
256K -40 ~ 85 176-LQFP 296-18918-ND◆ 15.98 14.91 13.85 TMS320R2812PGFA
-40 ~ 125 176-LQFP 296-18919-ND◆ 17.55 16.38 15.21 TMS320R2812PGFQ
36K 2K 8K Y Y 4 16 Y 2 Y 150 1.9 3.3 150 -40 ~ 85 176-LQFP 296-15990-5-ND◆ 23.48 21.91 20.35 TMS320F2812PGFA
Flash RAM ROM Operating Voltage (V) Frequency Temperature Digi-Key Price Each Texas Instruments
(16-Bit Word) (16-Bit Word) (16-Bit Word) Timers Serial MIPS Core I/O (MHz) (°C) Package Part No. 1 25 100 Part No.
TMS320C20x (Fixed Point)
32K 4.5K — 1 2 20 3.3 5 40 0 ~ 70 100-LQFP 296-2007-5-ND◆ 25.74 24.03 22.31 TMS320F206PZ
3.3 5 80 0 ~ 70 100-TQFP 296-2001-5-ND◆ 16.83 15.71 14.59 TMS320C206PZ80
— 4.5K 32K 1 2 40
3.3 5 80 -40 ~ 85 100-TQFP 296-2002-5-ND◆ 18.54 17.31 16.07 TMS320C206PZA80
3.3 3.3 80 0 ~ 70 100-LQFP 296-2012-5-ND 18.54 17.31 16.07 TMS320LC206PZ80
3.3 3.3 80 -40 ~ 85 100-LQFP 296-2013-5-ND 20.40 19.04 17.68 TMS320LC206PZA80
Flash RAM Timer I/O Frequency Digi-Key Price Each Texas Instruments
(KB) (KB) Channels ADC SPI SCI CAN2 3.3V (MHz) Package Part No. 1 25 100 Part No.
TMS470R1x
64 8 13 8 Ch, 10-Bit 2 2 SCC 40 48 80-LQFP 296-19270-ND◆ 8.70 6.96 5.88 TMS470R1A64PNT
128 8
16
16 Ch, 10-Bit 2 2 SCC
50
48
100-LQFP 296-17627-ND◆ 8.48 7.64 6.77 TMS470R1A128PZ
16 50 100-LQFP 296-19267-ND◆ 9.50 7.60 6.42 TMS470R1A128PZ-T
256 12
16
16 Ch, 10-Bit 2 2 SCC
50
48
100-LQFP 296-17754-ND◆ 9.76 8.79 7.80 TMS470R1A256PZ
16 50 100-LQFP 296-19268-ND◆ 9.50 8.55 7.59 TMS470R1A256PZ-T
16
93 144-LQFP 296-18723-ND 11.08 9.98 8.85 TMS470R1A288PGEA
288 16
12
12 Ch, 10-Bit 2 2 SCC
57
48
100-LQFP 296-19269-ND 12.74 11.48 10.18 TMS470R1A288PZA
12 93 144-LQFP 296-21881-ND◆ 11.08 9.98 8.85 TMS470R1A288PGET
12 57 100-LQFP 296-21882-ND◆ 10.58 9.53 8.45 TMS470R1A288PZ-T
384 32
16
12 Ch, 10-Bit 2 2 SCC
94
48
144-LQFP 296-18724-ND◆ 12.66 11.40 10.11 TMS470R1A384PGET
12 55 100-LQFP 296-19292-ND 12.16 10.95 9.71 TMS470R1A384PZ-T
512 32 32 16 Ch, 10-Bit 3 2 HECC 86 60 144-LQFP 296-19855-ND 14.74 13.28 11.78 TMS470R1B512PGET
768 48
32
16 Ch, 10-Bit 5 2 HECC
87
60
144-LQFP 296-19271-ND 19.43 18.13 16.84 TMS470R1B768PGE
32 87 144-LQFP 296-19335-ND◆ 17.55 16.38 15.21 TMS470R1B768PGET
1000 64 16 12 Ch, 10-Bit 2 3 HECC 93 60 144-LQFP 296-18591-ND◆ 20.33 18.97 17.62 TMS470R1B1MPGEA
