1 Introduction
1.1 Related Documentation from Texas Instruments
User's Guide
SLUU339 – December 2008
TPS2552/3, Power-Distribution Switch
With Adjustable Current-Limit EVM
This user’s guide describes the TPS2552/3DBVEVM and TPS2552/3DRVEVM evaluation modules (EVM).
This guide contains the EVM schematic, bill of materials, assembly drawing, and top and bottom board
layouts.
The TPS2552/3DBVEVM and TPS2552/3DRVEVM are evaluation modules (EVM) for Texas Instruments’
family of power-distribution switches with adjustable current-limit. These EVMs operate over a 2.5-V to
6.5-V range. An onboard jumper sets the output current-limit to either 0.5 A or 1 A. Test points provide
convenient access to all critical node voltages.
The silkscreen outline on the PCB top-side encloses components found in a typical USB application.
The PCB top-side accepts a power-distribution switch in a SOT23-6 package; the PCB bottom side
accepts a power-distribution switch in the smaller SON package with a thermal pad. These switches have
an enable input, an overcurrent status output, and overtemperature shutdown.
TPS2552, TPS2553 data sheet (TI Literature Number SLVS841)
SLUU339 – December 2008 TPS2552/3, Power-Distribution Switch 1
With Adjustable Current-Limit EVM
Submit Documentation Feedback
