5
13
12
16
15
1
2
3
KFF
RT
BP5
SGND
VIN
HDRV
SW
BP10
4
SYNC
11
ILIM
TPS4005xPWP
6
S
S/SD
7
V
FB
8
C
OMP
14BOOST
LDRV 10
P
GND
9
V
IN
V
O
+
–
+
–
UDG-03179
Product
Folder
Sample &
Buy
Technical
Documents
Tools &
Software
Support &
Community
TPS40054
,
TPS40055
,
TPS40057
SLUS593I –DECEMBER 2003–REVISED DECEMBER 2014
TPS4005x Wide-Input Synchronous Buck Controller
1 Features 3 Description
The TPS4005x is a family of high-voltage, wide-input
1
• Operating Input Voltage 8 V to 40 V
(8 V to 40 V), synchronous, step-down controllers.
• Input Voltage Feed-Forward Compensation
The TPS4005x family offers design flexibility with a
• < 1% Internal 0.7-V Reference
variety of user-programmable functions, including
soft-start, UVLO, operating frequency, voltage
• Programmable Fixed-Frequency up to 1-MHz
feed-forward, high-side current limit, and loop
Voltage Mode Controller
compensation.
• Internal Gate-Drive Outputs for High-Side and
Synchronous N-Channel MOSFETs
The TPS4005x uses voltage feed-forward control
techniques to provide good line regulation over the
• 16-Pin PowerPAD™ Package (θ
JC
= 2°C/W)
wide (4:1) input voltage range, and fast response to
• Thermal Shutdown
input line transients. Near-constant modulator gain
• Externally Synchronizable
with input variation eases loop compensation. The
externally programmable current limit provides pulse-
• Programmable High-Side Sense Short-Circuit
by-pulse current limit, as well as hiccup mode
Protection
operation using an internal fault counter for longer
• Programmable Closed-Loop Soft-Start
duration overloads.
• TPS40054 Source Only
Device Information
(1)
• TPS40055 Source and Sink
PART NUMBER PACKAGE BODY SIZE (NOM)
• TPS40057 Source and Sink With V
O
Prebias
TPS4005x HTSSOP (16) 5.00 mm x 4.40 mm
2 Applications
(1) For all available packages, see the orderable addendum at
the end of the datasheet.
• Power Modules
• Networking and Telecom
• Industrial and Servers
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
TPS40054: Not Recommended For New Designs
