16-Bit
'6
ADC
Gain
Die
Temperature
IR
Thermopile
Sensor
Voltage
Reference
Sensor
Amplifier
Digital
Control
Two-Wire
Interface
DRDY
ADR0
ADR1
SCL
SDA
V+
AGND DGND
TMP006
TMP006B
T
hot
T
cold
T
hot
T
hot
T
hot
+
Product
Folder
Sample &
Buy
Technical
Documents
Tools &
Software
Support &
Community
TMP006
,
TMP006B
SBOS518E –MAY 2011–REVISED APRIL 2015
TMP006/B Infrared Thermopile Sensor in Chip-Scale Package
1 Features 3 Description
The TMP006 and TMP006B are fully integrated
1
• Integrated MEMs Thermopile for Noncontact
MEMs thermopile sensors that measure the
Temperature Sensing
temperature of an object without having to be in direct
• Local Temperature Sensor for Cold Junction
contact. The thermopile absorbs passive infrared
Reference
energy from an object at wavelengths between 4 um
to 16 um within the end-user defined field of view.
– ±1°C (max) from 0°C to 60°C
– ±1.5°C (max) from –40°C to +125°C
The corresponding change in voltage across the
thermopile is digitized and reported with the on-chip
• Two-Wire Serial Interface Options:
die thermal sensor measurement through an I
2
C- and
– I
2
C and SMBus Compatible
SMBus-compatible interface. With this data, the
– TMP006 at 3.3 V
target object temperature can be calculated by an
external processor.
– TMP006B at 1.8 V
– Eight Programmable Addresses
The TMP007 is an enhanced version of the TMP006
or TMP006B. The TMP007 combines all the features
• Low Power
of the TMP006 and TMP006B with an additional math
– Supply: 2.2 V to 5.5 V
engine to perform all of the equations on chip,
– Active Current: 240 μA (typ)
allowing the target object temperature to be read
directly from the device. The TMP007 also provides
– 1-µA shutdown (max)
built-in nonvolatile memory for storing calibration
• Compact Package
coefficients.
– 1.6-mm × 1.6-mm × 0.625-mm DSBGA
The Infrared thermopile sensor is specified to operate
from –40°C to +125°C. It is possible to measure an
2 Applications
object temperature beyond the device operating
• Noncontact Temperature Sensing
range as long as the device itself does not exceed
the operating temperature range (–40°C to +125°C).
– Case Temperature
– Laser Printers
Device Information
(1)
– Power Relays
PART NUMBER PACKAGE BODY SIZE (NOM)
– Health and Beauty
TMP006
DSBGA (8) 1.60 mm × 1.60 mm
– HVAC Comfort Optimization
TMP006B
• Gas Concentration
(1) For all available packages, see the package option addendum
at the end of the datasheet.
• Flame Detection
Simplified Schematic
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
