Texas Instruments, Inc. PCN# 20140505002A
PCN Number:
20140505002A
PCN
Date:
11/03/2014
Title:
Qualify New Assembly Material set for Selected Device(s)
Customer
Contact:
PCN Manager
Phone:
+1(214)480-6037
Dept:
Quality Services
Change Type:
Assembly Site
Assembly Process
Assembly Materials
Design
Electrical Specification
Mechanical Specification
Test Site
Packing/Shipping/Labeling
Test Process
Wafer Bump
Site
Wafer Bump Material
Wafer Bump Process
Wafer Fab Site
Wafer Fab Materials
Wafer Fab Process
PCN Details
Description of Change:
Revision A is to make correction on the following:
(a) Remove select devices in the Product Affected Section (with strikethrough) and highlighted in
yellow. These devices were inadvertently added and not affected by this change.
Texas Instruments is pleased to announce the qualification of new assembly material set to add Cu as
an additional bond wire option for devices listed in “Product affected” section below. Devices will
remain in current assembly facility and piece part changes as follows:
Material
Current
Proposed
Wire
Au
Cu
Mount compound
A-03
A-16
Mold compound
R-07
R-21
Reason for Change:
Continuity of supply.
1) To align with world technology trends and use wiring with enhanced mechanical and
electrical properties
2) Maximize flexibility within our Assembly/Test production sites.
3) Cu is easier to obtain and stock
Anticipated impact on Fit, Form, Function, Quality or Reliability (positive / negative):
None.
Changes to product identification resulting from this PCN:
None.
Product Affected:
74AHC1G125DCKRE4
SN74AHC1G04DCKTE4
SN74AUC2G34DCKRG4
SN74LVC1G240DCK6
74AHC1G125DCKRG4
SN74AHC1G04DCKTG4
SN74AUP1G04DCKR
SN74LVC1G240DCKR
74AHC1G125DCKTE4
SN74AHC1G08DCK6
SN74AUP1G04DCKRE4
SN74LVC1G240DCKT
74AHC1G125DCKTG4
SN74AHC1G08DCKR
SN74AUP1G04DCKRG4
SN74LVC1G3157DCKR
74AHC1G126DCKRE4
SN74AHC1G08DCKRE4
SN74AUP1G04DCKT
SN74LVC1G32DCK6
74AHC1G126DCKRG4
SN74AHC1G08DCKRG4
SN74AUP1G04DCKTE4
SN74LVC1G32DCKR
74AHC1G126DCKTE4
SN74AHC1G08DCKT
SN74AUP1G04DCKTG4
SN74LVC1G32DCKRE4
74AHC1G126DCKTG4
SN74AHC1G08DCKTE4
SN74AUP1G17DCKR
SN74LVC1G32DCKRG4
74AHC1GU04DCKRE4
SN74AHC1G08DCKTG4
SN74AUP1G17DCKRE4
SN74LVC1G32DCKT
74AHC1GU04DCKRG4
SN74AHC1G09DCKR
SN74AUP1G17DCKRG4
SN74LVC1G32DCKTE4
