TSC2046
2
SBAS265C
www.ti.com
ABSOLUTE MAXIMUM RATINGS
(1)
+V
CC
and IOVDD
to GND.....................................................–0.3V to +6V
Analog Inputs to GND ............................................ –0.3V to +V
CC
+ 0.3V
Digital Inputs to GND ..........................................–0.3V to IOVDD + 0.3V
Power Dissipation ..........................................................................250mW
Maximum Junction Temperature ................................................... +150°C
Operating Temperature Range ....................................... –40°C to +85°C
Storage Temperature Range......................................... –65°C to +150°C
Lead Temperature (soldering, 10s) ............................................... +300°C
NOTE: (1) Stresses above these ratings can cause permanent damage.
Exposure to absolute maximum conditions for extended periods may degrade
device reliability.
ELECTROSTATIC
D
ISCHARGE SENSITIVITY
This integrated circuit can be damaged by ESD. Texas
Instruments recommends that all integrated circuits be handled
with appropriate precautions. Failure to observe proper han-
dling and installation procedures can cause damage.
ESD damage can range from subtle performance degrada-
tion to complete device failure. Precision integrated circuits
may be more susceptible to damage because very small
parametric changes could cause the device not to meet its
published specifications.
NOMINAL
PENIRQ MAXIMUM
PULLUP
INTEGRAL SPECIFIED
RESISTOR LINEARITY PACKAGE TEMPERATURE PACKAGE ORDERING TRANSPORT
PRODUCT VALUES ERROR (LSB) PACKAGE-LEAD DESIGNATOR RANGE MARKING NUMBER MEDIA, QUANTITY
TSC2046
50kΩ
±2 VFBGA-48 GQC –40°C to +85°C AZ2046 TSC2046IGQCR Tape and Reel, 2500
TSC2046-90
90kΩ
±2 VFBGA-48 GQC –40°C to +85°C AZ2046A TSC2046IGQCR-90 Tape and Reel, 2500
TSC2046
50kΩ
±2 TSSOP-16 PW –40°C to +85°C TSC2046I TSC2046IPW Rails, 100
" " " " " " " TSC2046IPWR Tape and Reel, 2500
TSC2046
50kΩ
±2 QFN-16 RGV –40°C to +85°C TSC2046 TSC2046IRGVT Tape and Reel, 250
" " " " " " " TSC2046IRGVR Tape and Reel, 2500
NOTE: (1) For the most current specifications and package information, see the Package Option Addendum located at the end of this data sheet.
PACKAGE/ORDERING INFORMATION
(1)
