SBAS265G − OCTOBER 2002 − REVISED JANUARY 2008
www.ti.com
2
ABSOLUTE MAXIMUM RATINGS
(1)
+V
CC
and IOVDD to GND −0.3V to +6V. . . . . . . . . . . . . . . . . . . . .
Analog Inputs to GND −0.3V to +V
CC
+ 0.3V. . . . . . . . . . . . . . . . .
Digital Inputs to GND −0.3V to IOVDD + 0.3V. . . . . . . . . . . . . . . . .
Power Dissipation 250mW. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum Junction Temperature +150°C. . . . . . . . . . . . . . . . . . . . . .
Operating Temperature Range −40°C to +85°C. . . . . . . . . . . . . . . .
Storage Temperature Range −65°C to +150°C. . . . . . . . . . . . . . . . .
Lead Temperature (soldering, 10s) +300°C. . . . . . . . . . . . . . . . . . . . .
(1)
Stresses above these ratings may cause permanent damage.
Exposure to absolute maximum conditions for extended periods
may degrade device reliability. These are stress ratings only, and
functional operation of the device at these or any other conditions
beyond those specified is not implied.
ELECTROSTATIC DISCHARGE SENSITIVITY
This integrated circuit can be damaged by ESD. Texas
Instruments recommends that all integrated circuits be
handled with appropriate precautions. Failure to observe
proper handling and installation procedures can cause damage.
ESD damage can range from subtle performance degradation to
complete device failure. Precision integrated circuits may be more
susceptible to damage because very small parametric changes could
cause the device not to meet its published specifications.
PACKAGE/ORDERING INFORMATION
(1)
PRODUCT
NOMINAL
PENIRQ
PULLUP
RESISTOR
VALUES
MAXIMUM
INTEGRAL
LINEARITY
ERROR
(LSB)
PACKAGE-
LEAD
PACKAGE
DESIGNATOR
SPECIFIED
TEMPERATURE
RANGE
PACKAGE
MARKING
ORDERING
NUMBER
TRANSPORT
MEDIA, QUANTITY
TSSOP-16
PW
−40°C to +85°C
TSC2046I
TSC2046IPW Rails, 100
TSSOP-16 PW −40°C to +85°C TSC2046I
TSC2046IPWR Tape and Reel, 2500
4x4, 1mm
TSC2046IRGVT Tape and Reel, 250
TSC2046I
50kΩ
±2
4x4, 1mm
QFN-16
RGV −40°C to +85°C TSC2046
TSC2046IRGVR Tape and Reel, 2500
TSC2046I 50kΩ ±2
QFN-16
RGV
−40 C to +85 C
TSC2046
TSC2046IRGVRG4 Tape and Reel, 2500
4x4
GQC −40°C to +85°C AZ2046 TSC2046IGQCR Tape and Reel, 2500
4x4
VFBGA-48
ZQC
−40°C to +85°C
BC2046
TSC2046IZQCT Tape and Reel, 250
VFBGA-48
ZQC −40°C to +85°C BC2046
TSC2046IZQCR Tape and Reel, 2500
TSC2046I
(2)
90kΩ
±2
4x4
GQC −40°C to +85°C AZ2046A TSC2046IGQCR-90 Tape and Reel, 2500
TSC2046I
(2)
90kΩ ±2
4x4
VFBGA-48
ZQC −40°C to +85°C BC2046A TSC2046IZQCR-90 Tape and Reel, 2500
(1)
For the most current package and ordering information, see the Package Option Addendum located at the end of this data sheet, or see the TI web
site at www.ti.com.
(2)
High-impedance version.
