ALUMINUM ELECTROLYTIC CAPACITORS
P.158
CAT.8100J
U
Specifications
Item Performance Characteristics
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Endurance
Shelf Life
Resistance to soldering
heat
Marking
Stability at Low Temperature
– 55 to +105°C
6.3 to 100V
1 to 3300µF
±20% at 120Hz, 20°C
After 2 minutes' application of rated voltage at 20°C, leakage current is not more than 0.01 CV or 3 (µA), whichever is greater.
After storing the capacitors under no load at 105°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4 clause 4.1 at
20°C, they shall meet the specified values for the endurance characteristics listed above.
The capacitors are kept on a hot plate for 30 seconds, which is
maintained at 250°C. The capacitors shall meet the characteristic
requirements listed at right when they are removed from the
plate and restored to 20°C.
6.3
2
3
4
Z—25°C / Z+20°C
Z—40°C / Z+20°C
Z—55°C / Z+20°C
Measurement
frequency :120Hz
Measurement
frequency:
120Hz at 20°C
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF. (φ12.5 to φ18)
Black print on the case top.
Capacitance Change
tan δ
Leakage current
Within ± 10% of the initial capacitance value
Less than or equal to the initial specified value
Less than or equal to the initial specified value
Rated voltage (V)
tan δ (MAX.)
Rated voltage
(
V
)
Impedance ratio
(
MAX.
)
10
2
3
4
16
2
3
4
25
2
3
3
35
2
3
3
50
2
3
3
63
2
3
3
80
2
3
3
100
2
3
3
6.3
0.26
10
0.19
16
0.16
25
0.14
35
0.12
50
0.10
63
0.08
80
0.08
100
0.07
Tangent of loss angle (tan δ)
The specifications listed below shall be met
when the capacitors are restored to 20°C
after the rated voltage is applied at 105°C
for the conditions listed at right.
U
U
U
h=hours
6.3 〜 50V
63 〜100V
〜7.7L
2000h
2000h
13.5L 〜
5000h
5000h
φ10×13.5L
5000h
5000h
10L
5000h
2000h
Rated Voltage
Size (mm)
Capacitance Change
tan δ
Leakage current
Within ± 30% of the initial capacitance value
200% or less than the initial specified value
300% or less than the initial specified value for 63V or more
Less than or equal to the initial specified value
A2
47 j
CD
(
φ4 to φ8
×
6.2
)
(
φ12.5 to φ18
)
(
φ8
×
10, φ10
)
0.3MAX.
φD±0.5
B±0.2
A±0.2A±0.2
C±0.2
0.5MAX.
E
H
H
0.3MAX.
φD±0.5
B±0.2
A±0.2A±0.2
C±0.2
0.5MAX.
E
L±0.3
L±0.5
Series
Capacitance
Lot No.
Lot No. Capacitance
Plastic platform
Plastic platform
Series
Trade mark
Voltage (j : 6.3V )
Voltage (E : 25V)
Negative
Positive
Negative
Positive
A2
220E
CD
Trade mark
Pressure
relief vent
1
1: Size φ8 × 6.2 only
2
2 :
Except :
φ
10 ×
7.7L
nichicon
Trade mark
Voltage
Series
Capacitance
Lot No.
φ D±0.5
L±1.0
C±0.2
B±0.2
E
H
Plastic platform
330 µF
CD
50V
H1015
Pressure
relief vent
0.3MAX.
0.5MAX.
Positive
A±0.2A±0.2
Negative
φ8 × 10L, φ10 × 10L, φ12.5 × 13.5L, φ16 × 16.5L, φ18 × 16.5L :
The vibration structure-resistant product is also available upon request, please ask for details.
V
Code
6.3
j
10
A
16
C
25
E
35
V
50
H
63
J
80
K
100
2A
Voltage
U
1
C
2
D
3
1
4
C
5
1
6
0
7
1
8
M
9
C
10
L
11
1
12
G
13
S
14
φ D
4 to 6.3
8 (6.2L)
CL
CL
8 (10L)
•
10(10L,13.5L)
NL
10(7.7L)
CL
12.5 to 18 NQ
Configuration
Size code
Taping
code
Capacitance tolerance (±20%)
Rated capacitance (100µF)
Rated voltage (16V)
Series name
Type
Code
A
B
C
E
L
H
4 × 5.8
1.8
4.3
4.3
1.0
5.8
0.5 to 0.8
5 × 5.8
2.1
5.3
5.3
1.3
5.8
0.5 to 0.8
6.3 × 5.8
2.4
6.6
6.6
2.2
5.8
0.5 to 0.8
6.3 × 7.7
2.4
6.6
6.6
2.2
7.7
0.5 to 0.8
(mm)
8 × 6.2
3.3
8.3
8.3
2.3
6.2
0.5 to 0.8
8 × 10
2.9
8.3
8.3
3.1
10
0.8 to 1.1
10 × 7.7
3.2
10.3
10.3
4.5
7.7
0.8 to 1.1
10 × 10
3.2
10.3
10.3
4.5
10
0.8 to 1.1
10 × 13.5
3.2
10.3
10.3
4.5
13.5
0.8 to 1.1
φ D × L
A
B
C
E
L
H
12.5
×
13.5
4.8
13.6
13.6
4.0
13.5
1.0 to 1.4
16 × 16.5
5.4
17.1
17.1
6.3
16.5
1.0 to 1.4
18 × 16.5
6.4
19.1
19.1
6.3
16.5
1.0 to 1.4
φ D × L
φ
4
to
10
φ
12.5
to
18
GS
MS
CodeSize
Type numbering system (Example : 16V 100µF)
Dimension table in next page.
Frequency
Coefficient
50Hz
0.35
120Hz
0.50
300Hz
0.64
1kHz
0.83
10kHz or more
1.00
Frequency coefficient of rated ripple current
ALUMINUM ELECTROLYTIC CAPACITORS
P.159
CAT.8100J
UCD
Rated Voltage
（V）
（code）
Rated
Capacitance
（µF）
Case Size
φD×L（mm）
tan δ
Leakage Current
（
µA
）
Impedance（Ω）
MAX.
（20℃/100kHz）
Rated Ripple
（mArms）
（105℃/100kHz）
Part Number
（
at 20℃ after
2 minutes
）
6.3
（0J）
22 4×5.8 0.26 3 1.35 90 UCD0J220MCL1GS
27 4×5.8 0.26 3 1.35 90 UCD0J270MCL1GS
33 5×5.8 0.26 3 0.70 160 UCD0J330MCL1GS
47 4×5.8 0.26 3 1.35 90 UCD0J470MCL6GS
47 5×5.8 0.26 3 0.70 160 UCD0J470MCL1GS
56 5×5.8 0.26 3.528 0.70 160 UCD0J560MCL1GS
68 6.3×5.8 0.26 4.284 0.36 240 UCD0J680MCL1GS
100 5×5.8 0.26 6.3 0.70 160 UCD0J101MCL6GS
100 6.3×5.8 0.26 6.3 0.36 240 UCD0J101MCL1GS
150 6.3×5.8 0.26 9.45 0.36 240 UCD0J151MCL1GS
220 6.3×5.8 0.26 13.86 0.36 240 UCD0J221MCL1GS
330 6.3×7.7 0.26 20.79 0.32 290 UCD0J331MCL1GS
330 8×6.2 0.26 20.79 0.26 300 UCD0J331MCL6GS
470 8×10 0.26 29.61 0.16 600 UCD0J471MNL1GS
470 10×7.7 0.26 29.61 0.18 600 UCD0J471MCL6GS
680 8×10 0.26 42.84 0.16 600 UCD0J681MNL1GS
680 10×7.7 0.26 42.84 0.18 600 UCD0J681MCL6GS
1000 8×10 0.26 63 0.16 600 UCD0J102MNL1GS
1500 10×10 0.26 94.5 0.080 850 UCD0J152MNL1GS
2200 10×13.5 0.26 138.6 0.080 950 UCD0J222MNL1GS
3300 12.5×13.5 0.30 207.9 0.080 1100 UCD0J332MNQ1MS
10
（1A）
22 4×5.8 0.19 3 1.35 90 UCD1A220MCL1GS
27 5×5.8 0.19 3 0.70 160 UCD1A270MCL1GS
33 4×5.8 0.19 3.3 1.35 90 UCD1A330MCL6GS
33 5×5.8 0.19 3.3 0.70 160 UCD1A330MCL1GS
47 6.3×5.8 0.19 4.7 0.36 240 UCD1A470MCL1GS
56 6.3×5.8 0.19 5.6 0.36 240 UCD1A560MCL1GS
68 6.3×5.8 0.19 6.8 0.36 240 UCD1A680MCL1GS
100 6.3×5.8 0.19 10 0.36 240 UCD1A101MCL1GS
150 6.3×5.8 0.19 15 0.36 240 UCD1A151MCL1GS
220 6.3×7.7 0.19 22 0.32 290 UCD1A221MCL1GS
220 8×6.2 0.19 22 0.26 300 UCD1A221MCL6GS
330 8×10 0.19 33 0.16 600 UCD1A331MNL1GS
330 10×7.7 0.19 33 0.18 600 UCD1A331MCL6GS
470 8×10 0.19 47 0.16 600 UCD1A471MNL1GS
470 10×7.7 0.19 47 0.18 600 UCD1A471MCL6GS
680 10×10 0.19 68 0.080 850 UCD1A681MNL1GS
1000 10×10 0.19 100 0.080 850 UCD1A102MNL1GS
1500 10×13.5 0.19 150 0.080 950 UCD1A152MNL1GS
2200 12.5×13.5 0.21 220 0.080 1100 UCD1A222MNQ1MS
16
（1C）
10 4×5.8 0.16 3 1.35 90 UCD1C100MCL1GS
15 4×5.8 0.16 3 1.35 90 UCD1C150MCL1GS
22 4×5.8 0.16 3.52 1.35 90 UCD1C220MCL6GS
22 5×5.8 0.16 3.52 0.70 160 UCD1C220MCL1GS
27 5×5.8 0.16 4.32 0.70 160 UCD1C270MCL1GS
33 6.3×5.8 0.16 5.28 0.36 240 UCD1C330MCL1GS
47 5×5.8 0.16 7.52 0.70 160 UCD1C470MCL6GS
47 6.3×5.8 0.16 7.52 0.36 240 UCD1C470MCL1GS
56 6.3×5.8 0.16 8.96 0.36 240 UCD1C560MCL1GS
68 6.3×5.8 0.16 10.88 0.36 240 UCD1C680MCL1GS
100 6.3×5.8 0.16 16 0.36 240 UCD1C101MCL1GS
Dimensions
