UM50E10C01
UM Series Subminiature Basic Switch, Single Pole Double Throw (SPDT), 250 Vac, 5
A, Straight Lever Actuator, Solder Termination
Product Specifications
Switch Type
Subminiature 12,7 mm H x 6,35 mm W x 20,3 mm L [0.5 in
H x 0.25 in W x 0.8 in L]
Sealed No
Ampere Rating 5 A
Circuitry Single Pole Double Throw (SPDT)
Actuator Straight Lever
Termination Solder
Operating Temperature
Range
-25 °C to 82 °C [-13 °F to 180 °F]
Voltage 250 Vac
Approvals CE, CSA, SEMKO, UL, VDE
Actuator Length 7,15 mm [0.281 in]
Contact Type Silver
Operating Force (O.F.) 0,56 N [2.0 oz] max.
Release Force (R.F.) 0,03 N [0.106 oz] min.
Pretravel (P.T.) 2,8 mm [0.110 in] max.
Overtravel (O.T.) 1,2 mm [0.047 in] min.
Differential Travel (D.T.) 0,8 mm [0.031 in] max.
Operating Position (O.P.)
8,4 mm ± 0,3 mm [0.331 in ± 0.012 in]
Housing Material Thermoplastic
CE mark 61058-1
UL File # E12252
CSA File # LR23413M167
Agency Approvals and
Standards
1054
Mounting Screw Size 2,3 mm [0.09 in]
Page 2 of 5Datasheet -- UM50E10C01
