Wirewound/Power Metal Strip
®
Surface Mount Resistor
www.vishay.com
Vishay Dale
Revision: 02-Dec-15
1
Document Number: 20051
For technical questions, contact: ww2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
Wirewound, Metal Film, and Power Metal Strip
®
Packaging
Notes
• WSLx = WSLP, WSLS, or WSLT
(1)
Dimensions in millimeters (inches)
GLOBAL
MODEL
SIZE
REEL: PUNCHED PAPER BULK
PACKAGING CODE
MAXIMUM
PIECES/REEL
TAPE
WIDTH
(1)
REEL
DIAMETER
(1)
PACKAGING CODE
MAXIMUM
PIECES/BAG
LEAD
(Pb)-FREE
TIN/LEAD
LEAD
(Pb)-FREE
TIN/LEAD
WSL0603,
WSLx0603
0603 EA TG 5000 8.0 (0.315) 178 (7.00) EK BA 100
WSL0805,
WSLx0805
0805 EA TG 5000 8.0 (0.315) 178 (7.00) EK BA 100
WSE0805 0805 EA TG 5000 8.0 (0.315) 178 (7.00) EK BA 100
GLOBAL
MODEL
SIZE
REEL: EMBOSSED PLASTIC BULK
PACKAGING CODE
MAXIMUM
PIECES/REEL
TAPE
WIDTH
(1)
REEL
DIAMETER
(1)
PACKAGING CODE
MAXIMUM
PIECES/BAG
LEAD
(Pb)-FREE
TIN/LEAD
LEAD
(Pb)-FREE
TIN/LEAD
WSK0612 0612 EA TA 4000 8.0 (0.315) 178 (7.00) EK N/A 100
WSL0612 0612 EA TA 4000 8.0 (0.315) 178 (7.00) EK BA 100
WSL1020 1020 EA TA 4000 12.0 (0.472) 178 (7.00) EK BA 100
WSL1206,
WSLx1206
1206 EA TA 4000 8.0 (0.315) 178 (7.00) EK BA 100
WSL1506E 1506 EA TA 4000 12.0 (0.472) 178 (7.00) EK BA 2500
WSL2010 2010 EA TA 4000 12.0 (0.472) 178 (7.00) EK BA 100
WSL2010E 2010 EA TA 4000 12.0 (0.472) 178 (7.00) EK BA 2500
WSC01/2,
WSF2012
2012 EA TA 2000 12.0 (0.472) 330 (13.00) EK BA 100
WSK2512,
WSL2512,
WSLx2512
2512 EA TA 2000 12.0 (0.472) 178 (7.00) EK BA 100
WSL2512E 2512 EA TA 2000 12.0 (0.472) 178 (7.00) EK BA 100
WSC0001,
WSC2515,
WSF2515
2515 EA TA 2000 16.0 (0.630) 330 (13.00) EK BA 100
WSL2726,
WSLx2726
2726 EA N/A 1500 16.0 (0.630) 330 (13.00) EK N/A 100
WSL2816 2816 EH TH 2000 12.0 (0.472) 178 (7.00) EK BA 100
WSH2818,
WSHM2818
2818 EA TA 3500 16.0 (0.630) 330 (13.00) EK BA 100
WSL3637 3637 EA TA 4000 16.0 (0.630) 330 (13.00) EK BA 100
WSL3921,
WSLx3921
3921 EA N/A 3000 16.0 (0.630) 330 (13.00) EK N/A 100
WSL4026,
WSLx4026
4026 EA N/A 1500 24.0 (0.945) 330 (13.00) EK N/A 100
WSC0002,
WSC4527,
WSF4527
4527 EA TA 1200 24.0 (0.945) 330 (13.00) EK BA 100
WSR2,
WSR3,
WSR5
4527 EA TA 1500 24.0 (0.945) 330 (13.00) EK BA 100
WSL5931,
WSLx5931
5931 EA N/A 1500 24.0 (0.945) 330 (13.00) EK N/A 100
WSC6927 6927 EA TA 725 32.0 (1.260) 330 (13.00) EK BA 100
WSZ7532 7532 EA TA 350 32.0 (1.260) 330 (13.00) EK BA 100
