Product datasheet

Characteristics

XMLG001D73TQ

pressure sensor XMLG - 0.08..1 bar -

1/4" NPT male

- 24 V - 0..10 V - set of 25

Main

Range of product

OsiSense XM

Product or component type

Electronic pressure sensors

Pressure sensor type

Pressure transmitter

Pressure sensor name

XMLG

Pressure sensor size

1 bar

Fluid connection type

1/4" - 18 NPT (male)

Controlled fluid

Air (

-15...125 °C)

Corrosive fluid (-15...125 °C)

Hydraulic oil (-15...125 °C)

Fresh water (0...125 °C)

Type of output signal

Analogue

Analogue output function

0...10 V, 3 wires

Electrical connection

3 pins 1 male connector M12

[Us] rated supply voltage

24 V DC, voltage limits: 11.4...33 V

Quantity per set

Set of 25

Type of packing

Group

Diameter

22.8 mm

Complementary

Pressure setting range

0...1 bar

Maximum permissible accidental pressure

2.7 bar

Destruction pressure

3 bar

Local display

Without

Electrical circuit type

Control circuit

Current consumption

< 20 mA

Materials in contact with fluid

Ceramic

FPM

PPS

Stainless steel type AISI 303

Operating position

Any position

Protection type

Load short-circuit

Reverse polarity

Surge withstand

1 kV (42 Ohm) conforming to EN/IEC 61000-4-5

500 kV (12 Ohm) conforming to EN/IEC 61000-4-5

[Uimp] rated impulse withstand voltage

0.5 kV

Response time on output

< 2 ms

Drift of the sensitivity

- 0.015 % of measuring range/°C

Drift of the zero point

- 0.015 % of measuring range/°C

Measurement accuracy

- 0.3 % of the measuring range

Repeat accuracy

- 0.1 % of the measuring range

Mechanical durability

>= 10000000 cycles

Product weight

0.095 kg

Length

48.5 mm

Environment

Standards

EN 50081-1

EN 50082-2

EN 61000-6-2

EN/IEC 60947-1

EN/IEC 60947-5-1

Theinformationprovidedinthisdocumentationcontainsgeneraldescriptionsand/ortechnicalcharacteristicsoftheperformanceoftheproductscontainedherein.

Thisdocumentationisnotintendedasasubstituteforandisnottobeusedfordeterminingsuitabilityorreliabilityoftheseproductsforspecificuserapplications.

Itisthedutyofanysuchuserorintegratortoperformtheappropriateandcompleteriskanalysis,evaluationandtestingoftheproductswithrespecttotherelevantspecificapplicationorusethereof.

NeitherSchneiderElectricIndustriesSASnoranyofitsaffiliatesorsubsidiariesshallberesponsibleorliableformisuseoftheinformationcontainedherein.
