3
Easy to mount (continued)
Display inversion function
>The display can be inverted vertically to adapt to the sensor’s installation
position.
OUT 2
bar
psi
kPa
MPa
OUT 1
OUT 2
bar
psi
kPa
MPa
OUT 1
Easy to set up
Menu naming and structure based on VDMA* standards
>The ergonomic design of OsiSense XMLR sets a new standard for ease of
confi guration.
Navigation using just two pushbuttons
>Two simple pushbuttons are all that is needed to navigate through an intuitive
menu structured according to VDMA standards.
1
2
1 Pushbutton to display a value or parameter or to save a selected value or
parameter and return to the menu.
2 Pushbutton to scroll from one menu to another or to increase a value or change
a parameter
Easy to maintain
At each device start up, all segments of the display light up briefl y to confi rm that it is
operating correctly.
The device can be tested using a diagnostic function which checks the whole
electronic signal processing chain. This function is accessible via the “Dia” menu.
It can be activated directly by the PLC by remote control via the test input
(on products which only have one analogue output).
OsiSense XMLR pressure sensors also include a recording of the high and low
pressure values measured since the last reset.
These values can be displayed via the Hi and Lo menus.
* VDMA: Verband Deutscher Maschinen und Anlagenbau e. V.
General presentation
(continued)
Electronic pressure sensors
OsiSense XM
Pressure sensors with 4-digit display, type XMLR
RUN
SP1
rP1
EF
rES
dS1
dr1
(extended
functions)
100%
NP
NP
8%
97%
5%
SP2
rP2
50s
0
50s
0
100% NP
8%
NP
97%
5%
Menu structure based on VDMA standards
30410-EN
version: 1.1
