CvP is supported if the fourth alphanumeric character from the left (“Z” in Figure below) is equal to, or
later in the alphabet than the letter in the "Revision with Fix" column of the table shown in the "Status"
section below.
Figure 2: Altera Date Code Marking Format
This figure explains the date code and revision marking format.
A X β Z ## #####
Die Revision
Status
Affects: Cyclone V GX and GT devices, except for 5CGXC3
Status: Devices that are CvP capable will be available in Q2 2013
The table below shows which revisions will have the fix.
Table 3: Device and Die Revisions
Note:
Future revisions beyond the one listed in the "Revision with Fix" column will be CvP capable.
Member Code Revisions without Fix Revision with Fix
5CGXC3 None A
5CGXC4 A B
5CGXC5 A B
5CGXC7 A and B C
5CGXC9 A B
5CGTD5 A B
5CGTD7 A and B C
5CGTD9 A B
Note: For Gen2 CvP updates or further inquiries, please contact mySupport.
Usermode High Icc
Description
When the affected device transitions into User mode, high Icc is observed, due to internal dataline
contention.
4
Usermode High Icc
ES-1035
2015.09.18
Altera Corporation
Cyclone V GX, GT, and E Device Errata
Send Feedback
