EVAL-AD7605-4SDZ/EVAL-AD7606SDZ/EVAL-
AD7607SDZ/EVAL-AD7608SDZ User Guide
UG-851
One Technology Way • P. O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com
Evaluating the AD7606/AD7606-6/AD7606-4, AD7607, AD7608, and AD7605-4
16-Bit Simultaneous Sampling, 8-/6-/4-Channel, SAR ADC
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Rev. A | Page 1 of 15
FEATURES
Full-featured evaluation board for the AD7606/AD7606-6/
AD7606-4, AD7607, AD7608, and AD7605-4
On-board power supplies
Standalone capability
System demonstration platform (SDP) compatible (EVAL-
SDP-CB1Z)
PC software for control and data analysis (download from the
AD7606/AD7606-6/AD7606-4, AD7607, AD7608, and
AD7605-4 product pages)
EVALUATION KIT CONTENTS
EVAL-AD7605-4SDZ/EVAL-AD7606SDZ/EVAL-AD7606-
6SDZ/EVAL-AD7606-4SDZ/EVAL-AD7607SDZ/EVAL-
AD7608SDZ evaluation board
Evaluation software CD for the AD7606/AD7606-6/AD7606-4,
AD7607, AD7608, and AD7605-4
Mains power supply adapter
Screw/nut kit
ADDITIONAL EQUIPMENT NEEDED
EVAL-SDP-CB1Z system demonstration platform
PC running Windows® Vista or Windows 7 with a USB 2.0 port
Signal source
SMB and USB cables
ONLINE RESOURCES
Documents Needed
AD7606/AD7606-6/AD7606-4, AD7607, AD7608, and
AD7605-4 data sheets
EVAL-AD7605-4SDZ/EVAL-AD7606SDZ/EVAL-AD7606-
6SDZ/EVAL-AD7606-4SDZ/ EVAL-AD7607SDZ/EVAL-
AD7608SDZ
user guide
Required Software
AD7606 evaluation software
Design and Integration Files
Schematics, layout files, bill of materials
EVALUATION BOARD DESCRIPTION
The EVA L -AD7605-4SDZ/E VA L -AD7606SDZ/EVA L -AD7606-
6SDZ/EVA L -AD7606-4SDZ/E VA L-AD7607SDZ/EVA L -
AD7608SDZ is a full-featured evaluation board that allows
users to easily evaluate the features of the AD7606/AD7606-6/
AD7606-4, AD7607, AD7608, and AD7605-4 analog-to-digital
converters (ADCs). The evaluation board can be controlled by
the E VAL -SDP-CB1Z SDP board via a 120-way SDP connector
(J2). The SDP board allows the evaluation board to be controlled
through the USB port of a PC using the AD7606 evaluation
software. The software is available for download from the AD7606/
AD7606-6/AD7606-4, AD7607, AD7608, and AD7605-4 product
pages or from the installer CD included in the evaluation board kit.
On-board components include an ADP7104ARDZ-5.0 5 V, low
noise low dropout regulator (LDO) and an ADR421 high
precision, band gap voltage reference.
Full data on the AD7606/AD7606-6/AD7606-4, AD7607,
AD7608, and AD7605-4 is available in the AD7606/AD7606-
6/AD7606-4, AD7607, AD7608, and AD7605-4 data sheets,
which should be consulted in conjunction with this user guide
when using the evaluation board. Full details on the EVA L -SDP-
CB1Z are available at the SDP board product page.
