Precision Low Drift 2.048 V/2.500 V
SOT-23 Voltage Reference
ADR380/ADR381
Rev. C
Information furnished by Analog Devices is believed to be accurate and reliable. However, no
responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other
rights of third parties that may result from its use. Specifications subject to change without notice. No
license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
Trademarks and registered trademarks are the property of their respective owners.
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781.329.4700 www.analog.com
Fax: 781.461.3113 ©2001–2010 Analog Devices, Inc. All rights reserved.
FEATURES
Initial accuracy: ±5 mV/±6 mV maximum
Initial accuracy error: ±0.24%/±0.24%
Low TCV
OUT
: 25 ppm/°C maximum
Load regulation: 70 ppm/mA
Line regulation: 25 ppm/V
Wide operating ranges
2.4 V to 18 V for ADR380
2.8 V to 18 V for ADR381
Low power: 120 μA maximum
High output current: 5 mA
Wide temperature range: −40°C to +85°C
Tiny 3-lead SOT-23 package with standard pinout
APPLICATIONS
Battery-powered instrumentation
Portable medical instruments
Data acquisition systems
Industrial process control systems
Hard disk drives
Automotive
PIN CONFIGURATION
V
IN
1
V
OUT
2
GND
3
ADR380/
ADR381
TOP VIEW
(Not to Scale)
02175-001
Figure 1. 3-Lead SOT-23
(RT Suffix)
GENERAL DESCRIPTION
The ADR380 and ADR381 are precision 2.048 V and 2.500 V
band gap voltage references featuring high accuracy, high
stability, and low power consumption in a tiny footprint.
Patented temperature drift curvature correction techniques
minimize nonlinearity of the voltage change with temperature.
The wide operating range and low power consumption make
them ideal for 3 V to 5 V battery-powered applications.
The ADR380 and ADR381 are micropower, low dropout
voltage (LDV) devices that provide a stable output voltage from
supplies as low as 300 mV above the output voltage. They are
specified over the industrial (−40°C to +85°C) temperature
range. The ADR380/ADR381 are available in the tiny 3-lead
SOT-23 package.
Table 1. ADR38x Products
Part Number Nominal Output Voltage (V)
ADR380 2.048
ADR381 2.500
