Application notes – Installation guide
The information contained herein is the property of LEDiL Oy, Salorankatu 10, FI-24240 SALO, Finland and is subject to change without
notice. Please visit www.ledil.com for additional information, such as the latest photometric files, 3D mechanical models, and application
notes relating to handling, gluing and taping.
6
General instructions of use
We strongly recommend that every customer fully tests and takes the necessary measures to ensure
that there is a complete compatibility of the chemical used with one’s particular product, LEDs
and other components. Testing and verifying of the adhesives, potting agents, coatings and their
combinations are always on the responsibility of the customer.
All surfaces where adhesive is applied must be clean, dry and free from grease and dirt. If cleaning of
the PCB surfaces is needed, please follow strictly the cleaning instructions of your LED manufacturer
– this is important as cleaning shall under no circumstances damage LEDs or other electronics
components on the PCB. Further note that optical components shall not be cleaned with any
chemicals – only micro fiber cloth may be used to remove fingerprints or other traces from handling.
When using adhesive, please follow the detailed instructions of the adhesive manufacturer. E.g. note
that different humidity and/or temperature levels may slow down the curing process of the adhesive
bond or shorten its lifetime
LEDiL’s note:
LEDiL cannot take responsibility for the results obtained by others whose methods we cannot control.
It is always the customer’s responsibility to determine the chemicals suitability for their product
and to take precautions for protection of property and persons against any hazards that may be
involved in the handling and use of chemicals. LEDiL disclaims all warranties, including warranties of
merchantability or suitability for a particular purpose, arising from use of any adhesive product. LEDiL
disclaims any liability for consequential or incidental damages of any kind, including lost profits.
Chemicals
Glues / adhesives / potting / thread lock
www.ledil.com/delo-adhesives
More information about bonding by DELO®
www.ledil.com/cree-chemical-compatibility
Tested materials and test procedure by CREE™
NOTE: These tests have been made only with LEDs and
are not necessarily compatible with optical materials.
Compatibility must be tested in advance by the customer.
