CC1310
SWRS181B –SEPTEMBER 2015–REVISED OCTOBER 2015
CC1310 SimpleLink™ Ultralow Power Sub-1-GHz Wireless MCU
1 Device Overview
1.1 Features
1
• Microcontroller • External System
– Powerful ARM
®
Cortex
®
-M3 – On-Chip Internal DC-DC Converter
– EEMBC CoreMark
®
Score: 142 – Very Few External Components
– EEMBC ULPBench™ Score: 158 – Seamless Integration With the SimpleLink™
CC1190 Range Extender
– Up to 48-MHz Clock Speed
• Low Power
– 128KB of In-System Programmable Flash
– Wide Supply Voltage Range: 1.8 to 3.8 V
– 8KB of SRAM for Cache (or as General-
Purpose RAM) – Active-Mode RX: 5.5 mA
– 20KB of Ultralow Leakage SRAM – Active-Mode TX at +10 dBm: 12.9 mA
– 2-Pin cJTAG and JTAG Debugging – Active-Mode MCU 48 MHz Running Coremark:
2.5 mA (51 µA/MHz)
– Supports Over-the-Air Upgrade (OTA)
– Active-Mode MCU: 48.5 CoreMark/mA
• Ultralow Power Sensor Controller
– Active-Mode Sensor Controller at 24 MHz:
– Can Run Autonomous From the Rest of the
0.4 mA + 8.2 µA/MHz
System
– Sensor Controller, One Wake Up Every Second
– 16-Bit Architecture
Performing One 12-Bit ADC Sampling: 0.85 µA
– 2KB of Ultralow Leakage SRAM for Code and
– Standby: 0.6 µA (RTC Running and RAM and
Data
CPU Retention)
• Efficient Code-Size Architecture, Placing TI-RTOS,
– Shutdown: 185 nA (Wakeup on External Events)
Drivers and Bootloader in ROM
• RF Section
• RoHS-Compliant Package
– Excellent Receiver Sensitivity –124 dBm Using
– 7-mm × 7-mm RGZ VQFN48 (30 GPIOs)
Long-Range Mode, –110 dBm at 50 kbps
– 5-mm × 5-mm RHB VQFN48 (15 GPIOs)
– Excellent Selectivity: 52 dB
– 4-mm × 4-mm RSM VQFN48 (10 GPIOs)
– Excellent Blocking Performance: 90 dB
• Peripherals
– Programmable Output Power up to +14 dBm
– All Digital Peripheral Pins Can Be Routed to
– Single-Ended or Differential RF Interface
Any GPIO
– Suitable for Systems Targeting Compliance With
– Four General-Purpose Timer Modules
Worldwide Radio Frequency Regulations
(Eight 16-Bit or Four 32-Bit Timers, PWM Each)
• ETSI EN 300 220, EN 303 131,
– 12-Bit ADC, 200 ksamples/s, 8-Channel Analog
EN 303 204 (Europe)
MUX
• FCC CFR47 Part 15 (US)
– Continuous Time Comparator
• ARIB STD-T108 (Japan)
– Ultralow Power Clocked Comparator
– Wireless M-Bus and IEEE 802.15.4g PHY
– Programmable Current Source
• Tools and Development Environment
– UART
– Full-Feature and Low-Cost Development Kits
– 2× SSI (SPI, MICROWIRE, TI)
– Multiple Reference Designs for Different RF
– I2C
Configurations
– I2S
– Packet Sniffer PC Software
– Real-Time Clock (RTC)
– Sensor Controller Studio
– AES-128 Security Module
– SmartRF™ Studio
– True Random Number Generator (TRNG)
– SmartRF Flash Programmer 2
– Support for Eight Capacitive Sensing Buttons
– IAR Embedded Workbench
®
for ARM
– Integrated Temperature Sensor
– Code Composer Studio™
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
