CC3100MOD
SWRS161 –DECEMBER 2014
CC3100MOD SimpleLink™ Certified Wi-Fi
®
Network Processor Internet-of-Things Module
Solution for MCU Applications
1 Module Overview
1.1 Features
1
– RX Sensitivity
• The CC3100MOD is a Wi-Fi Module that Consists
of the CC3100R11MRGC Wi-Fi Network Processor
• –94.7 dBm at 1 DSSS
and Power-Management Subsystems. This Fully
• –87 dBm at 11 CCK
Integrated Module Includes all Required Clocks,
• –73 dBm at 54 OFDM
SPI Flash, and Passives.
– Application Throughput
• Modular FCC, IC, and CE Certifications Save
• UDP: 16 Mbps
Customer Effort, Time, and Money
• TCP: 13 Mbps
• Wi-Fi CERTIFIED™ Modules, With Ability to
• Host Interface
Request Certificate Transfer for Wi-Fi Alliance
– Wide Range of Power Supply (2.3 to 3.6 V)
Members
– Interfaces With 8-, 16-, and 32-Bit MCU or
• Wi-Fi Network Processor Subsystem
ASICs Over a Serial Peripheral Interface (SPI)
– Featuring Wi-Fi Internet-On-a-Chip™
With up to 20-MHz Clock
– Dedicated ARM
®
MCU
– Low Footprint Host Driver: Less than 6KB
Completely Offloads Wi-Fi and Internet
– Supports RTOS and No-OS Applications
Protocols from the External Microcontroller
• Power-Management Subsystem
– Wi-Fi Driver and Multiple Internet Protocols in
– Integrated DC-DC Converter With a Wide-
ROM
Supply Voltage:
– 802.11 b/g/n Radio, Baseband, and Medium
• Direct Battery Mode: 2.3 to 3.6 V
Access Control (MAC), Wi-Fi Driver, and
– Low-Power Consumption at 3.6 V
Supplicant
• Hibernate With Real-Time Clock (RTC):
– TCP/IP Stack
7 μA
• Industry-Standard BSD Socket Application
• Standby: 140 μA
Programming Interfaces (APIs)
• RX Traffic: 54 mA at 54 OFDM
• 8 Simultaneous TCP or UDP Sockets
• TX Traffic: 223 mA at 54 OFDM
• 2 Simultaneous TLS and SSL Sockets
– Integrated Components on Module
– Powerful Crypto Engine for Fast, Secure Wi-Fi
and Internet Connections With 256-Bit AES
• 40.0-MHz Crystal With Internal Oscillator
Encryption for TLS and SSL Connections
• 32.768-kHz Crystal (RTC)
– Station, AP, and Wi-Fi Direct™ Modes
• 8-Mbit SPI Serial Flash RF Filter and
– WPA2 Personal and Enterprise Security
Passive Components
– SimpleLink Connection Manager for
– Package and Operating Conditions
Autonomous and Fast Wi-Fi Connections
• 1.27-mm Pitch, 63-Pin, 20.5-mm ×
– SmartConfig™ Technology, AP Mode, and
17.5-mm LGA Package for Easy Assembly
WPS2 for Easy and Flexible Wi-Fi Provisioning
and Low-Cost PCB Design
– TX Power
• Operating Temperature Range: –20°C to
• 17 dBm at 1 DSSS
70°C
• 17.25 dBm at 11 CCK
• 13.5 dBm at 54 OFDM
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
