Table 1: IP Core Upgrade Status
IP Core Status Description
IP Upgraded
Your IP variation uses the lastest version of the IP core.
IP Upgrade Optional
Upgrade is optional for this IP variation in the current version of the software.
You can upgrade this IP variation to take advantage of the latest development
of this IP core. Alternatively you can retain previous IP core characteristics by
declining to upgrade. Refer to the Description for details about IP core version
differences. If you do not upgrade the IP, the IP variation synthesis and
simulation files are unchanged and you cannot modify parameters until
upgrading.
IP Upgrade Required
You must upgrade the IP variation before compiling in the current version of
the software. Refer to the Description for details about IP core version
differences.
IP Upgrade Unspported
Upgrade of the IP variation is not supported in the current version of the
software due to incompatibility with the current version of the software. You
are prompted to replace the unsupported IP core with a supported equivalent
IP core from the IP Catalog. Refer to the Description for details about IP core
version differences and links to Release Notes.
IP End of Life
Altera designates the IP core as end-of-life status. You may or may not be able
to edit the IP core in the parameter editor. Support for this IP core
discontinues in future releases of the software.
IP Upgrade Mismatch
Warning
Warning of non-critical IP core differences in migrating IP to another device
family.
Follow these steps to upgrade IP cores:
1. In the latest version of the software, open the project containing an outdated IP core variation. The
Upgrade IP Components dialog automatically displays the status of IP cores in your project, along
with instructions for upgrading each core. Click Project > Upgrade IP Components to access this
dialog box manually.
2. To upgrade one or more IP cores that support automatic upgrade, ensure that the Auto Upgrade
option is turned on for the IP core(s), and then click Perform Automatic Upgrade. The Status and
4
Upgrading IP Cores
UG-SLDVRTL
2015.11.20
Altera Corporation
Altera Virtual JTAG (altera_virtual_jtag) IP Core User Guide
Send Feedback
