The MC68302 is a versatile one-chip processor that incorporates the main building blocks needed for the

design of a wide variety of networking and communications products. The MC68302 was the first device to

offer the benefits of a closely coupled, industry-standard, MC68000/MC68008 microprocessor core and a

flexible communications architecture. This multi-channel communications device may be configured to

support a number of popular industry-standard interfaces, including those for the Integrated Services Digital

Network (ISDN) basic rate and terminal adapter applications. Through a combination of architectural and

programmable features, concurrent operation of different protocols is easily achieved using the MC68302.

Data concentrators, modems, line cards, bridges, and gateways are examples of other suitable applications for

Efficient architecture involves a separate

RISC processor for handling communications

■

Three Serial Communications Controllers

(SCCs)

■

Support for HDLC/SDLC, Bisync, UART,

DDCMP, and Totally Transparent

protocols.

■

■

Strong 3rd Party tools support.

Typical Applications

■

ISDN equipment

■

Data Concentrators

■

Modems

■

■

MC68000/MC68008 Microprocessor Core

(May be disabled to use the IMP as a peripheral)

MOTOROLA’S MC68302

I

NTEGRATED MULTI-PROTOCOL PROCESSOR

MC68302 MICROPROCESSOR
