Analog and Interface Product Selector Guide 5
THERMAL MANAGEMENT PRODUCTS – Brushless DC Fan Controllers and Fan Fault Detectors
Part # Description
Typical
Accuracy
(°C)
Maximum
Accuracy
@ 25°C (°C)
Maximum
Temperature
Range (°C)
Vcc Range
(V)
Maximum Supply
Current (μA)
Features Packages
TC642 Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 1,000 FanSense™ Fan Monitor, minimum fan speed control 8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC642B Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 400
FanSense™ Fan Monitor, minimum fan speed control,
fan auto-restart
8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC646 Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 1,000 FanSense™ Fan Monitor, auto-shutdown 8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC646B Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 400
FanSense™ Fan Monitor, auto-shutdown,
fan auto-restart
8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC647 Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 1,000 FanSense™ Fan Monitor, minimum fan speed control 8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC647B Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 400
FanSense™ Fan Monitor, minimum fan speed control,
fan auto-restart
8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC648 Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 1,000 Over-temperature alert, auto-shutdown 8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC648B Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 400 Over-temperature alert, auto-shutdown, fan auto-restart 8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC649 Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 1,000 FanSense™ Fan Monitor, auto-shutdown 8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC649B Fan Manager Note 1 Note 1 -40 to +85 +3.0 to +5.5 400
FanSense™ Fan Monitor, auto-shutdown,
fan auto-restart
8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC650 Fan Manager ±1 ±3 -40 to +125 +2.8 to +5.5 90 Over-temperature alert 8-pin MSOP
TC651 Fan Manager ±1 ±3 -40 to +125 +2.8 to +5.5 90 Over-temperature alert, auto-shutdown 8-pin MSOP
TC652 Fan Manager ±1 ±3 -40 to +125 +2.8 to +5.5 90 FanSense™ Fan Monitor, over-temperature alert 8-pin MSOP
TC653 Fan Manager ±1 ±3 -40 to +125 +2.8 to +5.5 90
FanSense™ Fan Monitor, over-temperature alert,
auto-shutdown
8-pin MSOP
TC654
Dual SMbus
Fan Manager
Note 1 Note 1 -40 to +85 +3.0 to +5.5 320 FanSense™ Fan Monitor, RPM data 10-pin MSOP
TC655
Dual SMbus
Fan Manager
Note 1 Note 1 -40 to +85 +3.0 to +5.5 320
FanSense™ Fan Monitor, RPM data,
over-temperature alert
10-pin MSOP
TC664
Single SMbus
Fan Manager
Note 1 Note 1 -40 to +85 +3.0 to +5.5 320 FanSense™ Fan Monitor, RPM data 10-pin MSOP
TC665
Single SMbus
Fan Manager
Note 1 Note 1 -40 to +85 +3.0 to +5.5 320
FanSense™ Fan Monitor, RPM data,
over-temperature alert
10-pin MSOP
TC670
Predictive Fan
Fault Detector
N/A N/A -40 to +85 +3.0 to +5.5 150 FanSense™ Fan Monitor, programmable threshold 6-pin SOT-23
Note 1: These devices use an external temperature sensor. Accuracy of the total solution is a function of the accuracy of the external sensor.
THERMAL MANAGEMENT PRODUCTS – Temperature Sensors (Continued)
Part #
Typical
Accuracy
(°C)
Maximum
Accuracy
@ 25°C (°C)
Maximum
Temperature
Range (°C)
Vcc Range
(V)
Maximum Supply
Current (μA)
Features Packages
Serial Output Temperature Sensors (Continued)
TC72 ±0.5 ±1 -55 to +125 +2.65 to +5.5 400
SPI compatible interface, power-saving one-shot temperature measurement,
0.25°C temperature resolution
8-pin MSOP, 8-pin 3x3 DFN
TC74 ±0.5 ±2 -40 to +125 +2.7 to +5.5 350 SMbus/I
2
C™ compatible interface, 1°C temperature resolution 5-pin SOT-23A, 5-pin TO-220
TCN75A ±0.5 ±2 -40 to +125 +2.7 to +5.5 500
SMbus/I
2
C™ compatible interface, power-saving one-shot temperature
measurement, multi-drop capability, 0.0625°C to 0.5°C adjustable temperature
resolution
8-pin MSOP, 8-pin SOIC
TCN75 ±0.5 ±2 -55 to +125 +2.7 to +5.5 1,000
(1)
SMbus/I
2
C™ compatible interface, multi-drop capability, interrupt output,
0.5°C temperature resolution
8-pin MSOP, 8-pin SOIC
Note 1: TCN75 idle current is 250 mA. This device also has a Software Shutdown mode that reduces supply current to <1 A.
